ComfyUI custom nodes for NovelAI Diffusion V5 and earlier models, supporting text-to-image generation, img2img, inpainting, multi-character prompts, and prompt-weight conversion.

The YOLO/SAM detailer can process multiple detected regions sequentially. An optional PyTorch WD tagger automatically matches each region to an original character prompt, preserving its character and series names. Tagger output is used only for matching and is never added to the generation prompt. The tagger requires no ONNX runtime and downloads its model automatically on first use after the optional dependencies are installed.

Current version: 2.2.1

What's New in 2.2.1

Character X/Y inputs now use 0.0–1.0 in 0.1 increments, rounded to one decimal place and sent directly as normalized coordinates.
Default positions are unchanged (for example, the old 3 is now 0.3). When loading an older workflow, update saved coordinate values to the new range (5 becomes 0.5, 10 becomes 1.0); the old 0–10 input scale is no longer used.

What's New in 2.2.0

Added detail_mode=all for sequential detailing of multiple detected regions; existing workflows keep the first default.
Added automatic matching to original character prompts with the optional native PyTorch WD tagger. Tagger output is used only for matching and never added to generation prompts.
Preserved the original API mask grid while compositing each region through its own mask.
Serialized NovelAI requests with a minimum two-second delay after each HTTP attempt completes.
Validated two-face processing with a real ComfyUI/YOLO/SAM/WD/NovelAI run and 39 regression tests. Exact four-eye detection and reliable expression preservation remain outside the verified coverage.

What's New in 2.1.1

Added NovelAI Diffusion V5 Curated and V5 Full model selection.
V5 requests use params_version: 4 while older models keep params_version: 3.
V5 continues to use NovelAI's v4_prompt / v4_negative_prompt conditioning structure, including character prompts.
V5 Full uses native V5 inpainting. V5 Curated follows NovelAI's current client fallback to V4.5 Curated inpainting.
Autosaves are written under output/<date>/NAI_autosave/. A newly created nested folder may require refreshing the file browser or image feed before its first image appears in the listing.

Features

NovelAI generation: Text-to-image, img2img, and inpainting with NAI Diffusion V5, V4.5, V4, V3, and supported Furry models.
Multi-character prompts: Up to five character slots with separate positive/negative prompts and X/Y coordinates from 0.0 to 1.0 in 0.1 increments.
Multiple-region detailing: YOLO detection, SAM masks, and sequential NAI inpainting, with masked compositing for overlapping crops. Select detail_mode=all to process multiple regions.
Automatic character matching: An optional native PyTorch WD tagger selects the original character prompt for each region. Unclear matches are retried with a tighter crop and skipped if still ambiguous.
Controlled API requests: Requests run sequentially, with at least two seconds after each HTTP attempt completes before the next begins.
Prompt-weight conversion: Utilities for converting prompt-weight syntax between supported local formats and NovelAI.

Installation

Method 1: ComfyUI Manager (Recommended)

Open ComfyUI.
Click on Manager -> Custom Nodes Manager.
Search for ComfyUI_RS_NAI_API_Request.
Click Install.

Method 2: Manual Installation

Navigate to your ComfyUI custom_nodes directory.

Clone this repository:

git clone https://github.com/raspie10032/ComfyUI_RS_NAI_API_Request.git

Install dependencies:
```
pip install -r requirements.txt
```

Configuration (API Token)

To use these nodes, you must provide your NovelAI API Token.

Create a .env file in the root of this custom node directory (ComfyUI_RS_NAI_API_Request/.env).
Add your token to the file using the canonical variable name:
```
NAI_ACCESS_TOKEN=your_api_token_here
```
NAI_API_TOKEN is also accepted as a fallback for compatibility, but NAI_ACCESS_TOKEN is recommended.

Alternatively, you can set either variable as a system environment variable (NAI_ACCESS_TOKEN is checked first; NAI_API_TOKEN is checked if the first is absent).

Nodes

1. NAI Image Generator (`NovelAIGenerator`)

Main node for text-to-image generation.

2. NAI Character Prompt Select (`CharacterPromptSelect`)

Defines up to 5 characters with spatial coordinates (0.0–1.0 scale) for NAI V4+.

3. NAI Img2Img (`NAIImg2ImgNode`)

Performs image-to-image generation.

4. NAI Inpaint (`NAIInpaintNode`)

Specialized node for inpainting. Automatically snaps dimensions to 64px.

V5 Full uses its native V5 inpainting model. Until NovelAI releases V5 Curated inpainting, selecting V5 Curated follows the official client and uses V4.5 Curated inpainting.

5. NAI Face Detailer (`NAIFaceDetailerNode`)

Advanced face restoration using YOLO detection and SAM segmentation before sending to NAI API.

Requirement: Requires ComfyUI-Impact-Pack and ComfyUI-Impact-Subpack for detectors. BBOX_DETECTOR types are provided by ComfyUI-Impact-Subpack.

Behavior: Defaults to the first detected region. With detail_mode=all, plans all regions from the original image, assigns character prompts when enabled, and inpaints each region sequentially. Results are composited through masks with disjoint ownership where crops overlap. The crop targets a 1024 px longest side before 64 px dimension alignment. The API mask retains the original 32 px boxes at an 8 px stride. Region ownership clips whole 8 px cells at request resolution; only the separate composite mask is resized to the source crop. This avoids a mask downscale/upscale round trip that produced visible artifacts during live V5 Full testing.

Face Detailer outputs the composited image, a mask visualization, and a JSON matching report. The existing first two output socket indices are unchanged. If no face is detected the original image is returned on the first two outputs. Edited results are autosaved under NAI_autosave/face with metadata preserved from the NAI inpaint result.

5b. Detailer (`NAIFaceDetailerSegmNode`)

Same pipeline as NAI Face Detailer, but segm_detector is the required primary detector (defines the crop region) and bbox_detector is optional (additional source assigned to primary regions). SAM always produces the final mask. eye_bbox_detector and limit_opus_free behave identically to the Face Detailer node. Displayed in ComfyUI as Detailer.

5c. Automatic character matching (native PyTorch)

Both Detailer nodes accept the original CharacterPromptSelect output through characterPrompts. Connect NAI WD Tagger Loader (PyTorch) to tagger, select detail_mode=all and matching_mode=wd14 to process several characters.

Install the optional dependencies using the Python environment that runs ComfyUI: python -m pip install -r requirements-tagger.txt. Reuse its existing PyTorch/torchvision installation. No ONNX package is used. Ordinary generation and shared-prompt detailing do not import timm or download a tagger.

The loader provides device=auto (ComfyUI's selected device) or cpu, and a batch size. On the first WD match it downloads WD ViT Tagger v3's safetensors weights, config and tag vocabulary from the same pinned revision into ComfyUI/models/rs_wd_tagger. It caches the CPU model and offloads GPU weights back to CPU after tagging. Initial download/model load and CPU inference take additional time. The loader does not make a NovelAI request.

Tagger scores are used only to select a character. They never become positive or negative prompt text. Each request combines the Detailer's user-supplied shared/stage prompt with the selected original character prompt verbatim, and combines the corresponding original negatives. Character names, franchise names, qualifiers and weights remain in that original text even when the tagger does not know the character. Only that selected character is sent; full-image character coordinates are not reused for a crop.

Keep the Detailer prompt input for shared style/detail-stage instructions. Keep character identities, their franchise tags and character-specific attributes in the original character slots. A single flat prompt containing multiple mixed identities is not automatically split or assigned to characters. Tags should use Danbooru/NovelAI naming for matching; original strings are preserved for requests.

| Input | Behavior | |---|---| | detail_mode | first preserves detector order; all numbers valid regions from left to right, then top to bottom. | | matching_mode | shared applies the common prompt (optionally one original character); wd14 automatically selects among original character slots. Multiple slots require wd14. | | match_crop_factor | Context around each primary bbox for matching; independent of the inpaint crop_factor. Default 2.0. | | match_min_score | Minimum strongest discriminating tag score, default 0.25. This is a heuristic score, not a calibrated identity probability. | | match_min_margin | Minimum lead over the next character, default 0.08. | | max_regions | Maximum regions considered for API requests, default 16. Unprocessed regions still retain their mask ownership. | | preview_only | Show numbered detections and automatic matches, without reading the API token, running SAM, or making NAI requests. WD inference/download can still occur. |

Matching ignores shared attributes and common scene/quality tags, reduces the weight of eye color, and uses the strongest distinct evidence without penalizing longer original prompts. Ambiguous contextual crops are retried once at a tighter factor (up to 1.25). Still-ambiguous regions are skipped with the source pixels preserved; there is no manual mapping input and no forced ordering fallback. Multiple regions can belong to the same character, as with separate eye detections. This is not a one-to-one assignment constraint.

For eye refinement, prefer a face detector as the primary detector and an eye detector on eye_bbox_detector, so identity matching sees the head. Eye-only primary boxes are supported but may not contain enough identity evidence even after context expansion. Context that includes another character, similar identities, and characters absent from the tag vocabulary can remain ambiguous. There is no automatic semantic grouping of eye pairs into faces in this version.

The JSON matching_report records detection boxes, selected original character slot, match score/margin and planned/edited/skipped/empty-mask status. It contains no inferred prompt. A final edited PNG preserves the last API response metadata and adds rs_detailer_regions for the multi-region report. The last response's metadata alone is not a full multi-request workflow record.

Request serialization and pacing

All NAI calls from this extension share a process-local lock. The next request starts at least 2 seconds after the previous network attempt completes, even when another node calls the common helper. The first request does not have an artificial initial delay and no trailing sleep is added after the last request.

HTTP 429 is retried at most once. A valid numeric or HTTP-date Retry-After is respected, with a 2-second minimum and a 60-second fallback for invalid/missing values; the final 429 also leaves the cooldown in place. Every network attempt uses a 10-second connect / 300-second read timeout. Waiting for the lock/cooldown is cancellable through ComfyUI. An in-flight synchronous HTTP call finishes or times out before cancellation can take effect. This lock cannot coordinate other ComfyUI processes, programs, or separately installed extensions.

6. Prompt Converters

Prompt converter nodes translate weighted prompts between ComfyUI, NovelAI V4, and old NovelAI styles.

Converter Weight Rules

The converter should treat comma characters as tag separators in every supported syntax. This means a weighted range such as 1.3::tag1, tag2 :: contains two weighted tags, not one literal tag containing a comma.

NovelAI V4 numeric weights use scoped ranges:

1.3::tag1, tag2 :: applies 1.3 to tag1 and tag2.
1.3::tag1, tag2, tag3 has no closing ::, so 1.3 applies forward to all following comma-separated tags.
A closing :: ends the active numeric scope after the current comma-separated tag.

Old NovelAI weights use brace/bracket scopes:

{ opens a forward 1.05x scope for following comma-separated tags until a matching } closes it.
[ opens a forward 0.95x scope for following comma-separated tags until a matching ] closes it.
A closing } with no active { applies 1.05x backward to all previous parsed tags.
A closing ] with no active [ applies 0.95x backward to all previous parsed tags.
Mixed braces and brackets are handled by the same character-level scope rules. For example, {[tag]} multiplies 1.05 * 0.95, which is treated as approximately neutral after normalization.

When writing converted prompts, consecutive tags with the same effective weight should be merged into a single scope where possible:

1.05::tag1 ::, 1.05::tag2 :: can be written as 1.05::tag1, tag2 ::.
{tag1}, {tag2} can be written as {tag1, tag2}.

Old NovelAI brace/bracket syntax cannot exactly represent arbitrary numeric weights, negative weights, or zero weights. Those values are converted to the nearest practical old-style approximation when exporting to old NovelAI syntax.

Opus Free-Generation Protection

All generation nodes (NovelAIGenerator, NAIImg2ImgNode, NAIInpaintNode, NAIFaceDetailerNode) include a limit_opus_free parameter.

What it does: When enabled, the node clamps the request dimensions and step count to the conditions allowed under the NovelAI Opus free-generation tier, following the same approach as bedovyy/ComfyUI_NAIDGenerator.

What it does NOT do:

It does not auto-detect your account subscription tier.
It does not check your Anlas balance or block requests when balance is insufficient. The NovelAI API itself will reject any request that cannot be fulfilled.
An Anlas Tracker node is not included in this extension.

Set limit_opus_free to False if you have a paid subscription and want to generate at larger sizes or higher step counts.

Screenshots

(Screenshots placeholders)

Requirements

requests
Pillow
numpy
python-dotenv
segment_anything (SAM)
ComfyUI-Impact-Pack (Mandatory for Face Detailer node)
ComfyUI-Impact-Subpack (Mandatory for Face Detailer node; provides BBOX_DETECTOR types used for bbox loading)

Branch Comparison: `main` vs `Add_facedetail`

This section summarizes the differences introduced in the Add_facedetail branch relative to main.

Newly Added

| Item | Description | | :--- | :--- | | nai_api.py | New module housing shared NAI API helpers (request building, response parsing) extracted from generators.py. | | image_utils.py | New module with image manipulation helpers shared by the Face Detailer and generator nodes. | | NAIFaceDetailerNode | Full face detailer implementation: YOLO detection → SAM segmentation → NAI inpainting → crop-paste composite. Defaults to the first detected face; detail_mode=all enables multiple regions. | | Metadata-preserving autosave | Face Detailer results are autosaved with NAI metadata intact (same metadata written by the inpainting call). | | /face autosave subfolder | Face Detailer autosaves are written to NAI_autosave/face/ to keep them separate from standard generation outputs. | | n_samples=1 policy | Face Detailer enforces a single sample per NAI API call, matching NAI inpaint constraints. | | segment-anything>=1.0 | SAM added as an explicit runtime dependency in requirements.txt and pyproject.toml. | | limit_opus_free parameter | Manual toggle (default True) on all generation nodes that caps total pixels to ≤ 1,048,576 and steps to ≤ 28, matching Opus free-tier generation limits. No account detection or Anlas balance checking. |

Removed / Pruned

Behavior-Preserving Changes

load_dotenv() calls consolidated — previously called redundantly at module level in both generators.py and __init__.py; now called once.
__init__.py import and export variable names normalized to match the names exported by generators.py.
_get_save_path return signature simplified to a (path, filename) tuple (was a 5-tuple with unused empty-string fields).

Credits / Acknowledgments

See THIRD_PARTY_NOTICES.md for full details.

License

The source code in this repository is published under GPL-3.0-only. Full corresponding source is provided in this repository. The complete GPLv3 license text is in the COPYING file. See the LICENSE file for the short SPDX notice.

This is a factual license notice, not legal advice.

Workflow Examples

Files in workflow_example/ (example.json, example.png) are project-provided examples distributed with this project under GPL-3.0-only unless otherwise noted.

Detailer validation

Run python -m unittest discover -s tests -v for deterministic regression tests (detectors, SAM and NAI transport are simulated in pipeline tests).

For an optional real-weight CPU smoke after installing tagger dependencies, run python tests/smoke_wd_tagger.py --cache-dir /path/to/model-cache --output /path/to/result.json. This uses the repository screenshot and supplied face-box fixtures, then runs real PyTorch tagging and automatic matching, including the tighter-crop retry. It does not run live YOLO, SAM, ComfyUI UI execution or NovelAI generation.
