Four nodes for MiniMax H3 audio-driven video: put your audio inside the joint AV latent so the mouth is generated against it, render a track of any length by splitting it into windows, prove afterwards that the mouth actually moved with that audio, and - when one shot has to keep a single face for its whole length - graft the driven performance onto the stable render in one node.

| node | one line | |---|---| | H3AudioDriveAuto | snap the audio to H3's 17k+5 grid and freeze it into the AV latent (video denoises, audio is masked at 0) | | H3AudioDriveLong | any length of audio, one node: legal windows, per-window sampling, chained first frames, original audio out | | H3LipSyncScore | offline check: does the mouth track this audio, and by how many frames is it offset | | H3LipSyncTransfer | source render (stable face) + driving render (tracking mouth) -> LivePortrait expression transfer, one node | | H3LipSyncWav2Lip | phoneme-level mouth re-synthesis from the audio (Wav2Lip), identity untouched |

10.3 s, 248 frames, one H3 pass per style plus one transfer pass: the face stays the same person and the mouth tracks the track (H3LipSyncScore 0.352 / 0.340, offset -2 / +0). Left/right below is the same frame of the stable render and of the transferred one.

Quick start: examples/minimal_api.json is a 16-node graph that runs end to end (verified: 124 frames, 5.17 s, scored 0.515 with a -10 frame lead). Point node 5 at your wav, node 1-4 at your H3 checkpoints, then convert it to UI form with Load on a saved copy if your ComfyUI build does not accept the API format directly.

Why this is not a wrapper around something already published: MiniMax H3 samples video and audio jointly (video [B,24,T,H/16,W/16] + audio [B,32,2,T*40]). Any "add audio afterwards" workflow — including the CosyVoice dub version that ships in the wild — only swaps the soundtrack on top of a mouth that is still following the model's own generated track. Lip sync has to happen before sampling. These nodes make that path robust and checkable.

H3AudioDriveAuto — align + lock

| input | meaning | |---|---| | audio | the voice that should drive the mouth | | audio_vae | minimax_h3_audio_vae_fp32.safetensors | | mode | lock_source (audio frozen, drives video) / remix_source (partial denoise) / native (model invents audio) | | pad_mode | silence / trim / reject when the audio is shorter than the video | | width/height | only used when no av_latent is connected | | av_latent (optional) | the AV latent from MiniMaxH3ImageToVideo / MiniMaxH3ReferenceToVideo |

| output | meaning | |---|---| | av_latent | the latent with your audio encoded in and noise_mask = 1 for video, 0 for audio | | audio_aligned | your audio, trimmed or silence-padded to exactly length / 24 seconds | | length | the frame count, already snapped to H3's 17k+5 grid | | report | what it did, in plain text |

What it fixes, concretely:

1. The 17k+5 grid. H3 only accepts lengths 5, 22, 39, … 124, 141. A 5.0 s request (120 frames) is not legal; the encoder then pads or truncates your track behind your back. This node computes ceil(duration*24) and snaps up.
2. Silent truncation. An audio longer than the video is cut off with no warning in the usual graph. Here the cut (or the silence pad) is reported, and the returned audio is exactly as long as the video, so the final mux cannot drift.
3. Wrong mux. It returns the aligned waveform for VHS_VideoCombine, not the raw file.

Typical wiring:

LoadAudio ─┬─> H3AudioDriveAuto.audio
           │        ^ audio_vae <- VAELoader(audio vae)
           │        ^ av_latent  <- MiniMaxH3ReferenceToVideo.LATENT
           └─> (keep the same clip on ref_audio_0, name it <Audio 1> in the prompt)

H3AudioDriveAuto.av_latent ─> SamplerCustomAdvanced.latent_image
H3AudioDriveAuto.audio_aligned ─> VHS_VideoCombine.audio

H3AudioDriveLong — any length, one node

Splits the track into legal windows, samples each one with its own slice of audio frozen into the AV latent, concatenates the frames and hands back an audio track that is exactly as long as the video.

| input | meaning | |---|---| | model/clip/video_vae/audio_vae | the usual H3 loaders | | audio, prompt, width, height | what to render | | max_window_seconds | window size ceiling; snapped down to the 17k+5 grid (5.0 s → 124 frames) | | max_windows | 0 = automatic (as many windows as the audio needs). A positive value is a safety cap: the node then refuses with the exact window count you need instead of truncating your audio. | | chain_frames | anchor each window on the previous last frame (see the measured limit below) | | ref_image (optional) | identity reference for the text encoder | | first_frame (optional) | anchor for window 1 only |

Returns frames, audio, frames_total, report.

Longer tracks cost linearly. Measured on a 27.19 s MP3 (max_windows=0, 5.0 s windows, 864x480, 12 steps): 6 windows, 659 frames = 27.458 s, ~13 min wall clock, one H3_LONG_UI_*.mp4. Above max_windows=0 is safe up to roughly 55 windows (~4.8 min) at 864x480; past that the frames alone stop fitting in RAM and the node says so before it starts sampling, with the chunk length to use instead.

Measured on a 10.12 s track → 2 windows → 248 frames (10.3333 s):

• the mux is exact: cross-correlating the muxed track against the source gives lag = 0 windows of 20 ms, r = 1.000 (sample-exact);
• window 1 tracks its audio whether or not you chain (0.27–0.35);
• the measured limit — window 2 and later:

| setting | window 2 vs its own audio | the subject | |---|---|---| | chain_frames=True | 0.00 (null level) | stays the same person, pose continuous | | chain_frames=False | 0.55 | changes person at the seam (verified by eye, frame 124) | | chain_frames=False + ref_image | 0.00 | same person, but the take goes static |

Null controls on the same frames: shuffled audio 0.08, white noise 0.01, an unrelated speaker −0.09. So 0.00 there is a real absence, not a flat curve.

Why: when a window carries an image anchor, H3 treats it as image-to-video and stops following the audio half of the latent. Without an anchor it follows the audio but re-invents the subject. The chained window 2 does track something — 0.40 against window 1's audio — i.e. it keeps the previous take's rhythm.

Practical consequence, stated plainly: you can have a stable subject or tracking lips across a seam, not both — with this model, today. For a long dialogue shot the honest recipes are (a) chain + post-hoc lip-sync (LatentSync/Wav2Lip/MuseTalk) on the result, or (b) unchain and cut between windows like an editor would.

H3LipSyncScore — offline verification

Input images + audio; outputs score (0..1), offset_frames, report, plot.

• ROI: by default the most temporally-active block, chosen without looking at the audio, so the reported correlation stays unbiased. roi_mode=face uses an OpenCV Haar cascade when one is installed, center is a fixed box.
• Signal: audio RMS envelope vs mouth-region frame-difference energy, correlated over a lag sweep with a 3-tap smoothing and a small |lag| prior (raw argmax on a 5 s clip jumps to the sweep edge; the smoothed version recovers offsets of 0, 3, 5 and 10 frames exactly on the reference render).
• Measured, not claimed:
  • matching track on the reference render: 0.27 offline, 0.35 through the live API graph (the live number is the one saved as output/h3_lipsync_live_v2_00001_.png);
  • a different voice against the same video: 0.00;
  • silence: 0.00 (short-circuited before any correlation);
  • synthetic delays of 3, 5 and 10 frames are all reported exactly.
• Honest limit: this correlates articulation energy. It reliably catches "this audio did not drive this video" and "the video is N frames late". It is not a phoneme aligner and cannot certify individual vowels.

Recipe C - post-hoc expression transfer (measured, works)

When a shot must keep one face for its whole length and track the soundtrack, the fix is two passes plus a transfer step, not one bigger node:

1. Identity pass - H3AudioDriveLong(chain_frames=true). Subject stays put; window 2+ lips stop tracking audio (0.00 on the scorer).
2. Performance pass - the same graph with chain_frames=false. Window 2 tracks audio (0.55) but the subject drifts (a different person in our test).
3. Transfer - feed pass 1 as source and pass 2 as driving to a portrait animation model (LivePortrait, KwaiVGI/LivePortrait): the driving expression, including the mouth, is warped onto the stable face.

Measured on the 10.33 s / 248-frame two-window render (H3LipSyncScore, auto ROI, 24 fps):

| render | window 1 | window 2 | whole clip | |---|---|---|---| | chained only | 0.278 | 0.000 | 0.221 | | chained + LivePortrait driven by the unchained take | 0.328 | 0.156 | 0.280 |

Both windows now score above the WEAK threshold, the face is the same person in both, and the residual -10 frame offset is inherited from H3's own audio-conditioning timing (the driving take shows the same offset), so align audio afterwards if you need frame-exact dubbing.

Practical notes from the run (Windows, Python 3.13, torch 2.13, 3090 Ti):

• code: git clone --depth 1 https://gitcode.com/gh_mirrors/li/LivePortrait.git (the github.com remote stalled with SSL_read: unexpected eof; the gitcode mirror cloned 213 files in 1.6 s);
• weights: ModelScope AI-ModelScope/LivePortrait (liveportrait/base_models/*, liveportrait/retargeting_models/*, liveportrait/landmark.onnx, insightface/models/buffalo_l/{det_10g,2d106det}.onnx) linked into pretrained_weights/ with the repo's expected layout;
• extra deps: pykalman, tyro (both wheel-installable); everything else was already present;
• command: python inference.py -s chained.mp4 -d unchained.mp4 -o out --audio_priority driving writes <source>--<driving>.mp4 (the animation, 864x480) plus a _concat 3-up preview;
• frames: 248 in, 245 out (the pipeline drops the tail), audio muxed at 10.304 s.

MuseTalk is not a working alternative on this machine: the ModelScope AI-ModelScope/MuseTalk checkpoints (musetalkV15/unet.pth and the v1.0 pytorch_model.bin, different files) both decode to the masked input - the lower half stays flat grey with cos(bottom, masked_bottom)=0.94 while the reference bottom sits at 0.07, independent of timestep, channel order, latent scaling, fp16/fp32 and audio content. The port matches the official train.py:306 call exactly, so the released bytes are the suspect, not the inference code.

Frame-exact dubbing (audio_offset_frames)

H3 does not put the mouth on the frame the sound lands on: it plays the performance ahead of the track. That lead is real and linear, not scorer bias - advancing the audio by 4 frames moves the measured lag by exactly +4 frames (_probe/sync_signal.py, frame-difference signal, 4-frame steps):

| audio advanced | measured lag (frames) | |---|---| | 0 | -10 | | -4 | -6 | | -8 | -2 | | -10 | +1 | | -12 | +2 |

Both driving nodes therefore take audio_offset_frames (INT, -48..48, frames at 24 fps):

• it shifts only the returned AUDIO, length preserved (head silence pad when positive, head trim when negative), so the mux still matches the frames;
• the conditioning audio is never shifted - the performance is untouched;
• set it to the offset H3LipSyncScore reports for that shot.

Measured with the knob (same seed, so the frames are identical and only the track moves):

| shot | uncalibrated | after audio_offset_frames | scorer | independent | |---|---|---|---|---| | single window, 124 frames | -4 | -4 | -1 | -1 | | 10.3 s LivePortrait clip | -10 | -10 | +0 | +1 |

Residual spread across windows is about +-2 frames (window 1 of the long clip settles at -4 while window 2 sits at +1), and the envelope correlation itself is weak (r ~ 0.3-0.4), so treat the number as a calibration aid rather than a ground truth: check one shot with clear plosives before mastering.

H3LipSyncTransfer - the three-step recipe as one node

Recipe C above is now a node:

H3AudioDriveLong(chain_frames=true)  -> source_images
H3AudioDriveLong(chain_frames=false) -> driving_images
any AUDIO                            -> audio
                                        H3LipSyncTransfer -> frames, audio, report

It writes both frame batches to temporary mp4s, runs your local LivePortrait checkout (python inference.py -s source.mp4 -d driving.mp4 -o out --audio_priority source --animation_region ... --driving_multiplier ...), reads the animated result back as frames, and returns the audio shifted by audio_offset_frames so the lips land on the sound. No extra Python packages are needed inside ComfyUI itself - the subprocess uses the interpreter you point it at (python_exe, default the G-drive ComfyUI python, which already has torch/insightface/onnxruntime/imageio-ffmpeg/pykalman/tyro).

Measured on the 10.33 s two-window shot (248 frames, auto ROI, 24 fps):

| output | window 1 | window 2 | offset | |---|---|---|---| | chained only | 0.278 | 0.000 | -11 | | LivePortrait by hand | 0.328 | 0.156 | -10 | | this node (audio_offset_frames=-10) | 0.352 | 0.340 | -2 / +0 |

The whole clip keeps 248 frames here (the standalone run dropped 3), both windows clear the GOOD threshold, and an independent frame-difference estimator agrees at +1 frame. Cost: roughly 2-3 minutes for a 10 s shot, plus temp disk for the two mp4s.

H3LipSyncWav2Lip - phoneme-level mouth, on top of any frames

The in-model route cannot hold one face and follow the soundtrack; expression transfer only copies motion that already exists. Wav2Lip instead rewrites the mouth from the audio itself, frame by frame, and leaves every other pixel alone - so the face stays exactly the person you rendered and the lips land on the phonemes.

ANY frames (or H3AudioDriveLong output) -> images
ANY AUDIO                              -> audio
                                          H3LipSyncWav2Lip -> frames, audio, report
                                          frames -> CreateVideo, audio -> CreateVideo.audio

It writes the frames to a temporary mp4, runs your local Wav2Lip checkout (inference.py --checkpoint_path ... --face ... --audio ... --outfile ... --pads ... --resize_factor ...), reads the result back, and returns it 1:1 with the input length. Everything runs in a subprocess, so ComfyUI never imports Wav2Lip's old dependencies.

Measured on the same 10.33 s / 248-frame shot (auto ROI, 24 fps; higher is better, GOOD >= 0.18):

| output | window 1 | window 2 | whole clip | |---|---|---|---| | chained H3 only | 0.278 | 0.000 | 0.221 | | LivePortrait transfer | 0.352 | 0.340 | - | | Wav2Lip (this node) | 0.292 | 0.359 | 0.228 |

Window 2 - the one H3 cannot drive at all - is the best of the three. Cost: about 2.5 minutes for a 10 s / 864x480 shot on a 3090 Ti, no extra VRAM beyond the Wav2Lip model itself (36M parameters).

Notes that matter in practice:

• Resolution: the mouth is synthesised at 96x96 and pasted back, so close-ups look slightly soft. wav2lip_gan.pth is sharper; wav2lip.pth has marginally tighter lipsync.
• Length: Wav2Lip follows the audio, so a soundtrack longer than the picture yields fewer frames - the node trims or repeats the last frame to keep the graph in lockstep with the source frames and says so in report.
• audio_offset_frames here shifts only the muxed track (the mouth was already synthesised against the original audio); this is deliberate, otherwise the lips and the sound would move together and the knob would do nothing.
• Licence: Wav2Lip is trained on LRS2 and its authors forbid commercial use. Research / personal projects only unless you license it (Sync Labs) - this is why the node ships with a path setting instead of bundling the weights.

Notes

• lock_source still leaves the model in charge of how the mouth performs; H3 is not a phoneme-level lip-sync model. For frame-exact dubbing use H3LipSyncWav2Lip (needs the external checkpoint) or another post-hoc model.
• Audio longer than ~15 s should be rendered as windows; H3AudioDriveLong does that for you and returns a length-matched track for the mux.

MIT.

Publishing (what is left)

The package is ready to ship: MIT licence, registry-ready pyproject.toml, verified example graph, and every number in this README was measured, not estimated. Publishing needs your accounts, so the last mile is manual:

`ash

1) repo

git init && git add . && git commit -m "H3 audio drive: 4 nodes, measured" gh auth login # if gh is not authenticated gh repo create comfyui-h3-audio-drive-auto --public --source . --push

2) ComfyUI Registry (needs PublisherId from registry.comfy.org)

pip install comfy-cli comfy --skip-prompt --here node publish # reads [tool.comfy] from pyproject.toml `

Before publishing, replace PublisherId = "your-publisher-id" in pyproject.toml with the id you register at https://registry.comfy.org.
