ComfyUI RDNA35 Attention Research

English documentation (canonical).

日本語版

ComfyUI custom nodes for fixed 64-token block-diagonal self-attention on PyTorch ROCm with an optional Triton forward kernel. This is not a port of NVIDIA Blackwell TLX code.

The package also contains isolated gfx1151 research paths. None replaces normal ComfyUI attention globally:

• Exact full attention with an online-softmax Triton kernel for [BH,Q,D] x [BH,K,D].
• A MiniMax-H3-only QKV layout optimizer that keeps the selected ComfyUI attention backend unchanged.
• A training-free PISA HYD path using a compiled CK Tile statistics wheel, FlexAttention, and WMMA correction.

What This Implements

The operation splits the sequence into fixed blocks of 64 tokens. Tokens in block i attend only to keys and values from block i. This is exact for fixed block-diagonal attention, but it is not equivalent to normal full attention because cross-block attention is removed.

The Triton path is forward/inference only. There is no custom autograd or backward path.

Nodes

• RDNA35 Block Attention Diagnostics: reports PyTorch, HIP, device, best-effort gfx target, Triton availability, and RDNA3.5 detection.
• RDNA35 Patch Model Attention: installs a model-local optimized_attention_override on a cloned MODEL. It never globally monkey-patches ComfyUI attention.
• RDNA35 Patch PISA Attention: installs a model-local PISA override. Anima keeps its validated T=9216,D=128 spatial path. Explicitly marked SD1.5, SDXL, Wan, and LTX self-attention with T>=8192 uses the generic path; cross-attention, masks, short sequences, and unsupported devices chain to the previous ComfyUI backend.
• RDNA35 Patch MiniMax-H3 gfx1151 Attention: installs a model-local, MiniMax-H3-only BF16 layout optimizer. Long native interleaved Q/K/V views are packed before they are passed to the existing exact attention backend; short, masked, training, non-H3, and non-gfx1151 calls are unchanged.
• RDNA35 Fixed Block Attention Benchmark: creates synthetic Q/K/V tensors, compares reference, dispatch, PyTorch SDPA with a block-diagonal mask, and normal PyTorch full SDPA. Full SDPA is reported as a semantic contrast, not as an exact replacement.
• RDNA35 Exact Full Attention Benchmark: compares the gfx1151 online-softmax kernel with PyTorch SDPA for Anima-like self- and cross-attention shapes.
• RDNA35 MiniMax-H3 gfx1151 Attention Benchmark: compares native H3 interleaved Q/K/V against the H3-only packed layout on B=1,H=56,D=128.
• RDNA35 PISA Attention Benchmark: separates first-use compile time from GPU-event steady-state time and compares the CK/Flex hybrid with dense SDPA.
• RDNA35 Generic PISA Benchmark: compares generic PISA, ComfyUI PyTorch SDPA, Flash Attention, and the optional SageAttention ROCm7 backend on one synthetic input. SageAttention supports only its advertised head dimensions; unsupported shapes are reported without aborting the other measurements.

Measured gfx1151 results

MiniMax-H3 exact attention layout

MiniMax-H3 produces Q and K as interleaved views of its fused QKV projection. On gfx1151, the selected exact SDPA backend is much slower when it repeatedly traverses those large token strides. The H3-only override packs KV for 4608 <= T < 12000 and QKV for 12000 <= T <= 16500 in one torch.stack allocation, then calls the existing attention backend with the original arguments. It does not replace or approximate the attention math.

PyTorch 2.14 / ROCm 7.15 with AOTriton selected, BF16, five warmups and 20 alternating GPU-event samples produced:

| MiniMax-H3 shape | Native interleaved call | H3 packed call | Speedup | Time reduction | |---|---:|---:|---:|---:| | B=1,H=56,T=9170,D=128 (KV pack) | 311.660 ms | 86.736 ms | 3.593x | 224.925 ms (72.2%) | | B=1,H=56,T=16500,D=128 (QKV pack) | 2264.434 ms | 280.344 ms | 8.077x | 1984.090 ms (87.6%) |

Both outputs were bit-identical in the measured BF16 calls (max abs error=0, cosine similarity 1.0). This is an observation, while the correctness gate remains BF16 allclose(atol=rtol=5e-2). The timed region includes per-call packing, exact SDPA, and final output layout conversion; QKV projection, RMSNorm, RoPE, and creation of the input views are outside it. These are attention-call measurements, not full sampling-workflow timings. The stack allocation alone is about 251 MiB at T=9170 and 677 MiB at T=16500, in addition to the model tensors, attention output, and backend workspace. T<4608, T>16500, already-packed inputs, and unsupported calls remain on the existing path because packing is not validated as beneficial there.

A WSL2 Magpie comparison invoking the Windows ROCm Python passed correctness for both native and packed paths at BF16 T=4608 (2/2). Magpie performance was intentionally skipped and its performance scores were null, so its default Winner: Kernel 0 is not a speed ranking; the table uses direct GPU-event medians.

Anima PISA

The production comparison uses rdna35-pisa-ck 0.7.1 API 6 on the local PyTorch 2.14 ROCm 7.15 stack. The attention measurement is BF16 B=2,H=16,T=9216,D=128 with the validated 23/144 exact-block profile:

| Spatial self-attention backend | Complete call | Relative speed | Time reduction | |---|---:|---:|---:| | ComfyUI Flash Attention | 46.411 ms | 1.000x | baseline | | RDNA35 PISA CK/Flex fused | 25.121 ms | 1.848x faster | 21.290 ms (45.9%) |

The CK statistics kernel now fuses the Q/K/V centroids, first-order covariance matrix, and covariance norm used by the official HYD routing score. The native Q/K/V spatial pack is included in the complete call. The gfx1151 epilogue combines LSE weighting, FP32 correction, BF16 conversion, and block-major-to-raster output, while the spatial exact FlexAttention tile uses BLOCK_N=32.

PISA paper schedule versus Anima

Appendix E of PISA v2 keeps four initial layers dense for SD3.5 and FLUX.1. Its 70% or 85% sparsity is the fraction of key/value blocks approximated inside each PISA layer, not the fraction of transformer layers converted to PISA. The official FLUX processor consequently sends processor IDs 0-3 to dense SDPA and IDs 4 onward to PISA.

| Model | Transformer structure | Dense layers | PISA layers | Intra-layer sparsity | |---|---|---:|---:|---:| | SD3.5 Medium | 24 joint MMDiT blocks | 0-3 | 4-23 | 70% | | SD3.5 Large Turbo | 38 joint MMDiT blocks | 0-3 | 4-37 | 85% | | FLUX.1-dev | 19 double-stream + 38 single-stream blocks | 0-3 | 4-56 | 85% | | Cosmos-Predict2 2B / Anima | 28 homogeneous self-attention, cross-attention, MLP blocks | 0-19 | 20-27 | 84.03% (23/144 exact) |

Anima is a Cosmos-Predict2 2B fine-tune, not a FLUX transformer. Its 28 blocks have no 19/38 phase boundary: every block executes image self-attention, separate text cross-attention, and an MLP. The previous 4-27 schedule therefore copied a FLUX threshold across a different architecture and converted 24 of 28 Anima self-attention layers. That schedule caused unacceptable composition changes and is no longer the default or a recommended benchmark result.

BF16 Anima layer search

anima_aestheticV10.safetensors was measured at 1536x1536 with the standard KSampler, no INT8 ConvRot, no model compile, and no Spectrum. The prompts match the official Anima example.png; generation used 30 steps, CFG 5, Euler/simple, batch 1, and two matched seeds. SSIM, RGB cosine, and PSNR compare each image with the same-seed dense Flash output. Timings are process-order diagnostics rather than warm release medians.

| Sparse self-attention layers | Seed 856853657535148 E2E | SSIM / cosine / PSNR | Seed 856853657535149 E2E | SSIM / cosine / PSNR | Decision | |---|---:|---:|---:|---:|---| | none (Flash) | 142.974 s | 1 / 1 / inf | 128.265 s | 1 / 1 / inf | dense reference | | 20-27 | 129.650 s | .723942 / .963230 / 14.935 | 132.249 s | .630565 / .896732 / 10.794 | default aesthetic profile | | 24-27 | 129.220 s | .908147 / .993142 / 22.138 | 128.670 s | .781257 / .958885 / 14.717 | conservative fidelity profile | | 4-11 and 20-27 | 129.900 s | .607146 / .929997 / 12.196 | 132.720 s | .596093 / .885909 / 10.325 | rejected: text/layout regressions | | 0-3, 8-11, and 16-19 | 147.100 s | .575142 / .885335 / 10.003 | 145.910 s | .571344 / .894699 / 10.619 | rejected: slower and text regressions |

The 20-27 profile was selected for its judged image aesthetics; it is not the numerically closest profile. Use 24-27 when same-seed fidelity to Flash is more important. The node exposes inclusive first_pisa_layer and last_pisa_layer controls for further research, but one node represents one contiguous range. Chaining nodes can create disjoint research schedules.

The runtime verifier now expects eight PISA self-attention calls per model forward for the default profile, zero cross-attention calls, and zero eligible fallbacks. The reproducible BF16 and INT8 workflows explicitly store layers 20-27: pure BF16 and INT8 ConvRot. Their SaveImage nodes remain disabled so disk I/O is excluded from timing.

The progress bar is not a valid GPU timing source on asynchronous attention paths. Use synchronized Prompt E2E or GPU events, not tqdm iteration speed.

TODO

• Expand the quality matrix beyond two seeds and the official example prompt before promoting the 20-27 profile from experimental status. Compare perceptual metrics, prompt adherence, anatomy, text rendering, and per-layer attention error.

The generic benchmark below uses identical synthetic Q/K/V tensors and GPU-event medians after warm-up. Sage is SageAttention ROCm7 1.0.6. These are kernel-level measurements, not end-to-end image quality results:

| Shape | Generic PISA | PyTorch SDPA | Flash | SageAttention ROCm7 | |---|---:|---:|---:|---:| | FP16 SD1.5-like B=1,H=8,T=8192,D=40 | 4.394 ms | 5.791 ms | 3.896 ms | unsupported D=40 | | FP16 B=1,H=8,T=8192,D=64 | 4.912 ms | 5.278 ms | 5.296 ms | 5.689 ms | | BF16 B=1,H=4,T=16384,D=128 | 11.588 ms | 19.870 ms | 16.993 ms | 21.638 ms |

Generic PISA is intentionally approximate; its cosine similarity against dense SDPA on the three random inputs was 0.701518, 0.713715, and 0.805782. Kernel speed must therefore be paired with model-level quality validation before enabling a profile.

An LTX 2.3 image-to-video run at 768x768, 73 frames, and batch 2 completed normally but did not execute PISA. Runtime accounting observed 768 self-attention and 1536 cross-attention calls; the relevant self-attention sequence was T=1440, below the generic T>=8192 threshold, while text attention used T=77. Those calls correctly remained on the existing ComfyUI backend. This is compatibility evidence, not an LTX PISA speed result.

For unfiltered LTX video, ComfyUI now passes the patchified F,H,W token grid to the model-local attention override. Filtered guide tokens, guide masks, and mixed audio/video streams do not claim a spatial grid and remain on their safe fallback paths. The local LTX 2.3 checkpoint declares H=32,D=128; a synthetic BF16 B=1,T=8192 check on a 2x64x64 video grid measured 49.867 ms for HYD PISA, 492.331 ms for ComfyUI PyTorch SDPA, 40.981 ms for Flash, and 42.695 ms for SageAttention ROCm7. All outputs were finite; PISA cosine similarity against SDPA was 0.813123. PISA is substantially faster than the measured SDPA path at this large shape, but Flash remained 21.7% faster.

Wan self-attention now uses transformer_options["grid_sizes"] to group each frame into local 8x8 spatial blocks before generic PISA. Both square and rectangular spatial grids are supported when each dimension is divisible by 8; other shapes retain the generic linear-block path. A synthetic Wan-shaped BF16 check at B=1,H=12,T=8192,D=128, with a 2x64x64 token grid, produced finite output. Median kernel times were 21.936 ms for HYD PISA, 16.865 ms for ComfyUI PyTorch SDPA, and 13.553 ms for Flash; PISA cosine similarity against SDPA was 0.816548. This shape is therefore compatible but not performance-enabled by default evidence. No local Wan checkpoint was available for a model-level quality run. Causal Wan KV-cache attention is explicitly rejected by PISA and remains on the existing backend because cached Q and K/V lengths differ.

The generic Triton path was also checked for batch isolation with FP16 B=4,H=8,T=8192,D=64. All outputs were finite, and batch 0 from the four-image call exactly matched the same input executed alone.

An actual SDXL v-prediction workflow at 1536x1536 and 12 steps used dense attention in the four encoder-side high-resolution layers and generic 0th-order PISA in six decoder-side layers. The first real PISA call measured cosine 0.999624 and MAE 0.006393 against dense SDPA. The resulting image was coherent and free of stripes or non-finite pixels; against the same-seed Flash image it measured SSIM 0.679058 and RGB cosine 0.971958. Two warm paired runs averaged 20.193 seconds for PISA and 20.087 seconds for Flash, so this SDXL profile is compatible but does not demonstrate an end-to-end speedup on the measured workflow.

PISA is approximate and deliberately opt-in. The spatial path accepts only the validated 23-block sparse profile: 32 became non-finite during 30 steps, 33/36 were non-finite on the first step, and other sparse budgets are not production-validated. The 144-block profile remains available only as the dense SDPA validation path.

Install

ComfyUI Registry / Manager

After the first Registry release is approved, search for RDNA35 Attention in ComfyUI-Manager, or run:

comfy node install rdna35-attention

Git

Place this folder under:

C:\ComfyUI\custom_nodes\ComfyUI-RDNA35-Attention

Restart ComfyUI. Fixed-block nodes appear under RDNA35/Fixed Block Attention; the opt-in PISA patch appears under RDNA35/Attention Research.

The PISA patch additionally requires the wheel under native/rdna35_pisa_ck. Build it with the exact PyTorch/ROCm runtime and MAX_JOBS=32, then install it with pip install --no-deps. The wheel is BF16-only and rejects a different PyTorch/ROCm nightly before loading its extension.

Recommended runtime for the generic Triton research nodes:

• PyTorch ROCm build
• Triton compatible with that PyTorch ROCm build
• AMD RDNA3.5 target such as gfx1150, gfx1151, or gfx1152

The optional fourth benchmark backend is SageAttention ROCm7 1.0.6. Install its release wheel into the same Python environment as ComfyUI:

python -m pip install --no-deps https://github.com/guinmoon/SageAttention-Rocm7/releases/download/v1.0.6_rocm7/sageattention-1.0.6-py3-none-any.whl

The prebuilt PISA wheel is narrower: Windows, BF16, and gfx1151 only.

PyTorch ROCm still uses torch.cuda APIs and device="cuda" strings. ROCm detection is based on torch.version.hip.

Patch Safety

RDNA35 Patch Model Attention defaults to exact_only. In that mode, ordinary ComfyUI attention calls are left unchanged unless a call explicitly declares:

rdna35_attention_semantics = "fixed_block_diagonal"

experimental_force_block_local is opt-in. It still refuses calls that are not explicitly marked or otherwise proven self-attention. Cross-attention is never intentionally converted to block-local attention.

If a safe local model patch cannot be installed, the node returns the original model and includes the reason in the info output.

RDNA35 Patch Anima PISA Attention patches only the selected Anima image self-attention modules on a cloned model. The default anima_1536_spatial profile keeps layers 0-19 dense and converts layers 20-27. It never converts cross-attention, masked calls, FP16 calls, or another sequence length. Its intra-layer sparse profile is fixed at 23 exact blocks out of 144. Once a native/Flex call starts, failures are surfaced instead of retrying another backend on the same asynchronous stream.

RDNA35 Patch MiniMax-H3 gfx1151 Attention accepts only native comfy.ldm.minimax.model.MiniMaxH3Model calls with BF16 B=1,H=56,D=128, merged output, no mask, no GQA, no causal mode, no gradients, and 4608<=T<=16500. It only changes Q/K/V storage layout and chains a normal previous model-local override or the selected ComfyUI backend for the exact attention operation. If a container-aware model-local override is already installed, the H3 patch is not installed rather than bypassing that contract. The packed tensors live for one call and are not cached across executions.

Optimized Dispatch Conditions

The Triton kernel is used only when all of these are true:

• PyTorch ROCm/HIP is detected through torch.version.hip
• Q/K/V are on the same cuda device, which is the PyTorch ROCm device type
• Triton imports successfully
• dtype is float16 or bfloat16
• head dimension is 32, 64, or 128
• block_size == 64
• Q/K/V shapes match and represent self-attention
• layout is supported and normalized to contiguous [BH,T,D]
• no arbitrary mask is passed
• no input has requires_grad=True

Otherwise dispatch falls back to the PyTorch reference implementation with a reason. The ComfyUI patch falls back to the original attention backend for calls that are not known to be fixed block-diagonal.

Limitations

• Forward/inference only
• The MiniMax-H3 layout optimizer is ROCm gfx1151 BF16-only, uses additional temporary memory, and leaves T<4608 or T>16500 unchanged
• The optimized PISA paths are gfx1151-only
• Generic PISA prioritizes the fused CK HYD statistics profile for BF16 D=128; FP16 and other head dimensions up to 256 use the fused Triton statistics fallback
• SD1.5/SDXL, Wan, Wan AR, and LTX use generic PISA only for explicitly marked, unmasked self-attention with matching Q/K/V and T>=8192. Cross-attention, GQA, short sequences, Wan KV-cache attention, and LTX guide masks chain to the previous ComfyUI backend
• SDXL T=4032,D=64 fallback execution is verified. Wan dispatch is covered by synthetic contract tests. LTX 2.3 is verified to complete an actual 768x768, 73-frame workflow with safe short-sequence fallback, but neither model has a production PISA quality/performance profile
• A generic CK/Triton/Flex compile failure falls back to the previous attention backend; an out-of-memory error remains fatal so a second large allocation is not attempted
• First use compiles the selected-block FlexAttention kernel and the dense centroid approximation through Inductor/Triton; benchmark cold and steady-state runs separately
• PISA output is approximate and can change composition relative to Flash Attention
• Spatial sparse PISA accepts only the validated 23 exact blocks; other sparse budgets are rejected after real-model non-finite results at 32/33/36
• Fixed block_size=64
• No arbitrary mask in the Triton path
• No cross-attention conversion
• No CUDA extensions
• No NVIDIA Blackwell TLX features such as async dot, TMA, TMEM, mBarrier, or tcgen05
• No silent replacement of normal full attention

Tests

The runtime Python on this machine may not have pytest; the tests are unittest compatible:

$py = 'C:\Users\HarutoWatanabe\AppData\Local\Programs\Python\Python313\python.exe'
& $py -m unittest discover -s C:\ComfyUI\custom_nodes\ComfyUI-RDNA35-Attention\tests -v

Reference-only tests run on CPU. Triton tests skip automatically when ROCm/Triton is unavailable.

Benchmark

MiniMax-H3 native-layout comparison:

& C:\ComfyUI\custom_nodes\ComfyUI-RDNA35-Attention\scripts\run_minimax_h3_attention_bench.ps1 --tokens 9170 --warmup 5 --iterations 20 --check
& C:\ComfyUI\custom_nodes\ComfyUI-RDNA35-Attention\scripts\run_minimax_h3_attention_bench.ps1 --tokens 16500 --warmup 5 --iterations 20 --check

The launcher recreates the tested Windows ROCm environment, requires gfx1151 and AOTriton, and creates the native H3 interleaved Q/K/V layout. --check compares the packed path with the unmodified exact SDPA output before timing. The CLI is the canonical performance measurement; the ComfyUI benchmark node is a quicker 2-warmup/5-sample alternating diagnostic and reports its selected backend.

Fixed-block comparison:

$py = 'C:\Users\HarutoWatanabe\AppData\Local\Programs\Python\Python313\python.exe'
& $py C:\ComfyUI\custom_nodes\ComfyUI-RDNA35-Attention\scripts\bench_fixed_block_attention.py --tokens 256 --head-dim 64 --dtype float16 --mode auto

The benchmark reports:

• PyTorch reference loop latency for fixed block-diagonal attention
• PyTorch SDPA with a block-diagonal mask, which has the same fixed-block semantics
• PyTorch full SDPA, which is normal full attention and not semantically equivalent
• Triton latency and speedups only if the Triton backend actually runs
• The full-SDPA semantic delta vs fixed-block reference, so the output difference is visible
