AFFINE

Adaptive Field Filtering by Intermittent Noise Enhancement

AFFINE is a comprehensive ComfyUI node suite that performs sparse Adaptive Field Filtering by Intermittent Noise Enhancement in latent space to steer diffusion results during sampling.
It works by applying controlled scale and bias (z' = scale * z + bias) to masked regions of the latent tensor, enabling precise control over brightness, contrast, and detail enhancement without collapsing noise structure.

The suite includes:

• Core Affine Nodes - Basic latent space transformations
• Integrated Samplers - KSampler and Custom Sampling with built-in affine scheduling
• Ultimate SD Upscaler Ports - Tiled upscaling with affine enhancement
• Pattern Noise Generation - AFFINE augmented random noise for custom sampling
• Modular Options System - Granular control over all parameters (also a super options node for the adventurous)

Examples

[▶︎] WAN Example

[▶︎] 720p -> 2k Example

Things to take note of:

• The background rock quality is improved.
• The trees and brush look more naturally dispersed.
• Roads are more realistic
• The foreground detail is essentially better preserved.
• The overall contrast is reduced.

---

🧠 How it works (ELI5)

• Controlled enhancement: Apply scale and bias transforms to specific regions defined by procedural masks.
• Pattern-based masking: Choose from 20+ patterns including Perlin noise, spectral noise types, geometric patterns, and content-aware masks.
• Temporal consistency: Static or per-frame mask generation for stable video processing.
• External gating: Use custom mask images to limit where effects are applied.
• Modular configuration: Mix and match common options with pattern-specific parameters.
• Integrated workflows: Built-in samplers handle scheduling automatically, or use manual latent transforms between sampling passes.

The core transformation: z' = scale * z + bias where the mask determines the blend between original and transformed values.

---

✨ Why AFFINE?

• Improves Quality – Enhance detail in light LoRA outputs or tame overly contrasted/burned results from speed-boosting LoRAs.
• Works in latent space – Avoids costly VAE decode/encode cycles and raster-space artifacts.
• Sparse control – Apply adjustments selectively using sophisticated mask patterns.
• Stable video – Temporal modes maintain consistency or controlled variation across frames.
• Flexible integration – Use standalone transforms, integrated samplers, or tiled upscaling workflows.
• Advanced patterns – 20+ mask types from simple geometric to complex spectral and content-aware patterns.
• Ultimate SD Upscaler compatibility – Tiled processing with world-aligned noise and affine enhancement.

---

🔧 Workflow Options

Option 1: Manual Latent Transform (Classic)

1. Run KSampler Advanced or Custom Sampling for high-noise steps
2. Apply Latent Affine or Latent Affine Simple
3. Resume with second sampler for low-noise steps

Option 2: Integrated Samplers

• Use KSampler Affine or KSampler Affine Advanced for automatic scheduling
• Use Custom Sampler Affine Advanced for custom sampling workflows
• Configure affine schedule, interval, and pattern parameters directly

Option 3: Tiled Upscaling

• Use Ultimate Affine KSampler - USDU nodes for large image processing
• Combines upscaling, tiling, and affine enhancement in one step
• Supports custom samplers and sigma schedules

---

📋 Node Reference

Core Affine Nodes

Latent Affine

The main affine transformation node with full configurability.

Inputs:

• latent – Input latent tensor
• scale – Multiplicative factor (1.0 = no change, <1 darkens, >1 brightens)
• bias – Additive offset (-2.0 to 2.0)
• pattern – Mask pattern (20+ options including procedural, spectral, and content-aware)
• temporal_mode – static or per_frame for video
• seed – Random seed for procedural patterns
• external_mask – Optional IMAGE input for custom masking
• options – Base options DICT (use WASLatentAffineCommonOptions)
• noise_options – Pattern-specific options DICT

Returns:

• latent – Transformed latent
• mask – Generated mask for visualization

Latent Affine Simple

Streamlined version with auto-tuned parameters for quick results.

Inputs:

• latent – Input latent
• scale – Multiplicative gain (0.95-0.98 for subtle darkening)
• noise_pattern – Auto-tuned mask pattern
• seed – Random seed
• temporal_mode – static or per_frame
• frame_seed_stride – Seed increment per frame

Returns:

• latent – Adjusted latent
• mask – Generated mask

Integrated Samplers

KSampler Affine / KSampler Affine Advanced

Drop-in replacements for standard KSamplers with built-in affine scheduling.

Key Parameters:

• affine_interval – Apply affine every N steps
• max_scale / max_bias – Peak transformation values
• affine_schedule – WASAffineScheduleOptions DICT for timing curve
• affine_seed / affine_seed_increment – Seed management
• All standard KSampler parameters

Custom Sampler Affine Advanced

Advanced custom sampling with affine integration.

Inputs:

• noise / guider / sampler / sigmas – Standard custom sampling inputs
• latent_image – Input latent
• Affine parameters (same as KSampler variants)

Returns:

• output – Final latent
• denoised_output – Denoised latent

Ultimate SD Upscaler Ports

Ultimate Affine KSampler - USDU

Full upscaling with model-based upscaling and affine enhancement.

Key Features:

• upscale_model / upscale_factor – Pre-upscale configuration before tiling.
• Tiling parameters – tile_width, tile_height, tile_padding, mask_blur.
• tiled_decode – Uses ComfyUI's built-in VAE tiled decode (compression-aware) to reduce VRAM peaks for large images/videos.
• Batching controls – batch_size for processing the IMAGE batch in chunks; merge_frames_in_batch to merge [B,F,H,W,C] decodes into [B*F,H,W,C] for safe concatenation.
• Noise determinism – deterministic_noise and global_noise_mode to make outputs batching-invariant and ignore NOISE input if desired.
• Cross-batch blending – overlap_blend_count and overlap_blend_curve to softly crossfade at batch boundaries without dropping frames.
• Full affine parameter set – affine_interval, max_scale, max_bias, pattern, affine_seed, affine_seed_increment, affine_schedule, and optional external_mask gating with options/noise_options.

Ultimate Affine KSampler (No Upscale) - USDU

Tiled processing without pre-upscaling.

Ultimate Affine KSampler (Custom) - USDU

Supports custom samplers and sigma schedules via custom_sampler and custom_sigmas while keeping the same tiling/affine controls.

Advanced: Tiled Decode Parameters

When tiled_decode is enabled, you can fine-tune the VAE tiled decode behavior:

• tiled_tile_size – Target output tile size (in pixels, pre-compression). Larger is fewer tiles (faster) but higher VRAM peaks.
• tiled_overlap – Output-space overlap (in pixels, pre-compression). Higher overlap improves tile blending but increases work.
• tiled_temporal_size – Temporal window for video decode (frames, pre-compression). 0 disables temporal tiling.
• tiled_temporal_overlap – Temporal overlap in frames (pre-compression). Helps blend across temporal windows.

Notes:

• Parameters are adjusted automatically using the VAE’s spatial/temporal compression so the decode receives latent-space tile_x, tile_y, and overlap.
• Sanity checks ensure overlap <= tile_size/4 and temporal_overlap <= temporal_size/2.

Batch Join Smoothing and Determinism

• merge_frames_in_batch – ComfyUI IMAGE tensors are 4D [B,H,W,C] by convention. This option only applies when a decoder returns a temporal IMAGE tensor [B,F,H,W,C] (e.g., some tiled temporal VAE decodes). In that case, frames are flattened to [B*F,H,W,C] so batches with different frame counts can be concatenated safely. Has no effect for standard 4D images.
• overlap_blend_count / overlap_blend_curve – Crossfade the last K images of a batch into the first K of the next batch at concatenation time (no frame drops). Curves: cosine (smooth) or linear.
• deterministic_noise – Generate local noise with per-item seeds to make results independent of batch size.
• global_noise_mode – Force deterministic noise for the entire run (ignores NOISE input) for strict batching invariance.

Pattern Noise Generation

Affine Pattern Noise

Generates structured noise by augmenting base ComfyUI noise with procedural patterns.

Inputs:

• pattern – Noise pattern type
• seed – Random seed
• affine_scale – Pattern amplitude multiplier
• normalize – Center and scale pattern
• affine_bias – Additive bias
• options / noise_options – Pattern parameters

Returns:

• noise – Structured noise generator

---

🎨 Available Patterns

Spectral Noise Types

• white_noise – Uniform frequency spectrum
• pink_noise – 1/f frequency falloff (natural)
• brown_noise / red_noise – 1/f² falloff (warmer)
• blue_noise – High-frequency emphasis
• violet_noise / purple_noise – f² emphasis (harsh)
• green_noise – Mid-frequency band-pass
• black_noise – Sparse narrowband spectrum

Geometric Patterns

• checker – Checkerboard tiles
• bayer – Ordered dithering matrix
• solid – Constant alpha mask

Procedural Patterns

• perlin – Smooth fractal noise (organic)
• worley_edges – Cellular noise emphasizing edges
• poisson_blue_mask – Blue-noise Poisson-disk distance field
• cross_hatch – Oriented gratings and cross-hatch
• tile_oriented_lines – Per-tile oriented lines
• dot_screen_jitter – Halftone dots with jitter
• velvet_noise – Sparse high-frequency impulses

Frequency Domain

• ring_noise – Narrow annulus in frequency domain
• highpass_white – High-pass filtered white noise

Content-Aware (from latent)

• detail_region – High texture/variance areas
• smooth_region – Low detail areas
• edges_sobel – Sobel edge detection
• edges_laplacian – Laplacian edge detection

External

• external_mask – Use provided IMAGE directly

---

🔧 Options System

Common Options (WASLatentAffineCommonOptions)

Base parameters that apply to all patterns:

• mask_strength – Scales mask intensity (0.0-2.0)
• threshold – Binarize mask if > 0 (0.0-1.0)
• invert_mask – Invert after threshold/blur
• blur_ksize / blur_sigma – Gaussian blur for soft edges
• clamp / clamp_min / clamp_max – Output value clamping
• frame_seed_stride – Seed increment per frame (temporal mode)
• compute_device – Where to generate masks (auto/cuda/cpu)
• sharpen_enable / sharpen_sigma / sharpen_amount – Unsharp masking

Pattern-Specific Options

Each pattern type has dedicated option nodes:

WASPerlinOptions

• perlin_scale – Base feature size (larger = smoother)
• perlin_octaves – Number of octaves (1-8)
• perlin_persistence – Amplitude falloff per octave
• perlin_lacunarity – Frequency multiplier per octave

WASWorleyEdgesOptions

• worley_points_per_kpx – Cell density per 1000 pixels
• worley_metric – Distance metric (L2/L1)
• worley_edge_sharpness – Edge emphasis exponent

WASPoissonBlueOptions

• poisson_radius_px – Minimum dot spacing
• poisson_softness – Distance field smoothing

WASCrossHatchOptions

• hatch_freq_cyc_px – Line frequency
• hatch_angle1_deg / hatch_angle2_deg – Hatch angles
• hatch_square – Square wave vs sine
• hatch_phase_jitter – Random phase variation
• hatch_supersample – Anti-aliasing factor

WASRingNoiseOptions

• ring_center_frac – Ring center (fraction of Nyquist)
• ring_bandwidth_frac – Ring thickness

WASHighpassWhiteOptions

• highpass_cutoff_frac – Butterworth cutoff
• highpass_order – Filter steepness

WASTileLinesOptions

• tile_line_tile_size – Tile dimensions
• tile_line_freq_cyc_px – Line frequency per tile
• tile_line_jitter – Orientation randomness

WASDotScreenOptions

• dot_cell_size – Halftone cell size
• dot_jitter_px – Dot center randomness
• dot_fill_ratio – Coverage per cell

WASGreenNoiseOptions / WASBlackNoiseOptions / WASVelvetOptions

• Spectral and impulse noise parameters
• See node tooltips for detailed ranges

WASCheckerOptions / WASBayerOptions

• checker_size / bayer_size – Pattern scale

WASDetailRegionOptions / WASSmoothRegionOptions

• content_window – Kernel size for content analysis

Affine Schedule Options (WASAffineScheduleOptions)

Controls timing and intensity curves for integrated samplers:

• start / end – Active range (0.0-1.0 of total steps)
• bias – Curve bias toward start/end
• exponent – Power curve shaping
• curve – Easing function (linear, sine, cubic, etc.)
• start_offset / end_offset – Value adjustments

Returns: Schedule DICT + visualization plot

---

🏞️ External Mask Gating

Use external masks to limit where affine effects are applied:

• Connect a grayscale IMAGE to external_mask input
• Set pattern to any procedural pattern (not external_mask)
• The generated pattern mask is multiplied by your external mask
• Affine transforms only apply where both masks are bright

Use Cases:

• Apply effects only to specific objects or regions
• Combine with segmentation masks for targeted enhancement
• Create complex composite effects with multiple mask layers

---

📂 Installation

Manual

1. Clone the repository to your ComfyUI/custom_nodes directory:

   cd ComfyUI/custom_nodes
   git clone https://github.com/WASasquatch/was_affine.git


2. Restart ComfyUI via Manager or console

Manager

1. Open Manager and click "Install Custom Nodes"
2. Search "WAS Affine" and click install on the custom node by author WAS.
3. Restart ComfyUI via Manager's main menu.

Dependencies: Standard ComfyUI installation (torch, numpy). Note: Doesn't requires UltimateSDUpscale nodes.

---

🧪 Tips & Best Practices

General Guidelines

• Start subtle: Latent space is sensitive - scale=0.95 can be quite strong
• Model sensitivity varies: Some models respond more dramatically than others
• Flux/Krea models: May need positive scale values (inverted behavior)
• Lightning LoRAs: Combine with lower CFG (1-2) for best results

Pattern Selection

• Organic content: perlin, worley_edges work naturally
• Architectural/geometric: checker, bayer, cross_hatch
• Fine detail work: velvet_noise, highpass_white, ring_noise
• Content-aware: detail_region for textures, smooth_region for skies

---

📜 License

MIT – Free to use, modify, and share with attribution.

---

🙏 Acknowledgments

• ComfyUI team for the excellent software
• Ultimate SD Upscaler and ComfyUI wrapper developers
• Community feedback and testing contributions like "Ansel" and "Lucifer".
