ComfyUI-NynxzH3

ComfyUI-NynxzH3

MiniMax H3 nodes for ComfyUI: conditioning, prompt rewriting, sampling and latent handling.

Installation

cd ComfyUI/custom_nodes
git clone https://github.com/Nynxz/ComfyUI-NynxzH3

Restart ComfyUI. Requires ComfyUI 0.30.0 or newer.

Nodes

| node | category | purpose | |---|---|---| | H3 Canvas | Nynxz/H3 | Canvas size and duration | | H3 Inputs | Nynxz/H3 | Keyframes and several references on one node | | H3 Image | Nynxz/H3 | Image reference or keyframe | | H3 Video | Nynxz/H3 | Video reference, with soundtrack | | H3 Audio | Nynxz/H3 | Audio reference | | H3 Encode | Nynxz/H3 | Conditioning and AV latent | | H3 Extras | Nynxz/H3 | Canvas values from the wire | | H3 Rewrite Prompt | Nynxz/H3/Prompt | Build the prompt the rewriter LoRA was trained on | | H3 Rewrite Clean | Nynxz/H3/Prompt | Trim a rewriter response to the production prompt | | H3 CLIP LoRA | Nynxz/H3/Prompt | Apply a LoRA to a text encoder, no MODEL input | | H3 Block Cache | Nynxz/H3/Sampling | Skip the transformer stack on low-change steps | | H3 Depth Skip | Nynxz/H3/Sampling | Skip named blocks | | H3 Detail Schedule | Nynxz/H3/Sampling | Sigmas with a separate refinement phase | | H3 Row Chunk | Nynxz/H3/Sampling | Keeps projections under CUDA's int32 limit | | H3 Sliding Window | Nynxz/H3/Sampling | Banded attention over the video rows | | H3 Reference Isolate | Nynxz/H3/Sampling | Stops the reference prefix attending to the target | | H3 Decode Frames | Nynxz/H3/Latent | Decode selected frames | | H3 Latent Slice | Nynxz/H3/Latent | Slice a latent on the token axis |

Assets and the canvas chain on one h3_inputs wire into H3 Encode, in any order. Unwired nodes fall back to H3's defaults.

The reasoning and measurements behind the sampling nodes are in docs/sampling-notes.md.

Conditioning

H3 Canvas

h3_inputs?, width, height, seconds → h3_inputs, report

Sets the canvas. Both axes snap to 32px, and the duration snaps up to H3's frame grid (n % 17 == 5), so 5s becomes 124 frames. Resolution picking is left to a dedicated resolution node.

H3 Inputs

first_frame?, last_frame?, pictures, audios, size, h3_inputs? → h3_inputs, report

Keyframes and several references on one node. pictures (×9) and audios (×4) grow as you fill them, and a slot names the tag it answers to — picture_2 is <Picture 2>. The report gives the real tags, since anything wired upstream shifts them.

Reference video goes on H3 Video, not here — core pairs ref_video_audio_N with ref_video_N by slot number, so a silent clip in an early slot sends every later soundtrack to the wrong video (why).

H3 Image

image, role, size, h3_inputs? → h3_inputs

One asset per node, for when a single reference is all you need or the role varies. role is reference, first_frame or last_frame, which selects the task on H3 Encode. Only images can be keyframes.

H3 Video

frames, fps, audio?, detail, latent?, h3_inputs? → h3_inputs

fps must match the source. H3 presents reference video at 24 fps with timestamps derived from it, so a wrong value plays the reference at the wrong speed and mislabels its timestamps. Frames are resampled nearest-neighbour.

detail (full/half/quarter) reduces the resolution the reference is fed in at. Reference rows are processed every step, so half cuts roughly a quarter off the run and off peak VRAM; alignment is unaffected. latent accepts this clip's existing H3 latent, skipping the VAE encode.

H3 Audio

audio, h3_inputs? → h3_inputs

Audio reference. Requires audio_vae on H3 Encode.

H3 Encode

clip, vae, audio_vae?, prompt, mode, keyframe_instruction, h3_inputs? → positive, LATENT, report

Replaces MiniMax H3 Image to Video and MiniMax H3 Reference to Video. The task follows from what is wired — nothing → t2va, first and/or last frame → fl2va, references → ref2va — and mode forces one of those names instead of a second vocabulary.

Forcing matters because fl2va and ref2va cannot be combined; that is a ComfyUI constraint, not this pack's. With both wired, fl2va wins, reference images still reach Qwen3-VL as <Picture i> blocks, and anything set aside is named in report.

Forcing fl2va with no frame roles marked uses the first two pictures as the anchors, which is what H3's own prompt form calls them. An explicit role always wins. keyframe_instruction writes the alignment line an fl2va prompt should open with, using the snapped duration.

H3's trained range is ~124–362 frames (5–15s). Longer is untested and degrades badly — sung and spoken content becomes unintelligible well before a minute. For longer pieces, chain 10–15s segments with video continuation + audio reference.

H3 Extras

h3_inputs, mode → width, height, length, frame_count, latent_t, audio_t, seconds, task, is_keyframes, is_references, summary

Reads the canvas back off the wire, including the frame count it snapped up to.

Prompt

Turn a one-line idea into a full H3 prompt in-graph, using lightx2v's rewriter LoRA on a Qwen3-VL-8B text encoder. ComfyUI-format LoRAs: nynxz/Qwen3-VL-8B-ComfyUI.

CLIPLoader (qwen3vl_8b, type: stable_diffusion)
  -> H3 CLIP LoRA        the rewriter LoRA, strength 1.0
  -> Generate Text       sampling_mode: off (greedy), max_length 2048-4096
       prompt <- H3 Rewrite Prompt.prompt
       image  <- H3 Rewrite Prompt.reference_images
  -> H3 Rewrite Clean    -> prompt for H3 Encode

H3 Rewrite Prompt

prompt, task, resolution, duration, first_frame?, last_frame?, system_prompt? → prompt, reference_images

Renders the system prompt, task header and reference-frame placeholders exactly as the adapter was trained, and batches the reference images in placeholder order — images bind to <|image_pad|> by position, so that ordering is what keeps them aligned.

| task | frames | placeholders | |---|---|---| | t2va | none | — | | i2va | first_frame | Picture 1 = first frame | | l2va | last_frame | Picture 1 = final frame | | fl2va | both | Picture 1 = first, Picture 2 = last |

Duration is 4–15s. Two frames travel as one IMAGE batch, so fl2va scales last_frame onto first_frame when they differ. ref2va is not supported by the adapter — H3 Encode will condition on references the rewriter cannot write for.

H3 Rewrite Clean

generated_text → prompt, integrated_multimodal_description, overall_soundscape, non_diegetic_music

Strips chat tokens, code fences and any preamble, then splits the three fields. Text it does not recognise passes through unchanged.

H3 CLIP LoRA

clip, lora_name, strength → clip

The core Load LoRA node demands a MODEL input that a rewrite-only graph does not have. Chain two to stack — an abliteration LoRA under the rewriter, say. Keep the rewriter off any encoder that also builds conditioning: it changes how the model writes.

Sampling

H3 Block Cache

model, threshold, max_consecutive, start_percent, end_percent, verbose → MODEL

Reuses the transformer stack's output on steps where it barely changes. Measured 80s → 30s on a 5s clip at aggressive settings. threshold is an accumulated relative-L1 budget, so it means the same at any resolution or duration; 0 disables it. 0.05–0.1 is usually free, past 0.2 motion smears.

H3 Depth Skip

model, blocks, start_percent, end_percent, mode → MODEL, report

Skips named blocks: "3-17", "3-17, 22", ranges inclusive. Empty changes nothing. mode defaults to attention_only, which keeps the MLP and still captures most of the saving. Blocks 3–17 are the quietest band on the released checkpoints — confirm against your own output.

H3 Detail Schedule

structure_steps, detail_steps, split, shift, detail_spacing → SIGMAS, report

Wire into SamplerCustomAdvanced in place of a scheduler. Budgets structure and refinement separately without changing the shift curve — every sigma still lies on it. A 15/8 split reads out a nat and a half deeper into high SNR than plain shift-12 at the same step count (why).

H3 Row Chunk

model, chunk_rows → MODEL, report

Splits the qkv projection and MLP into row chunks so their intermediates stay under CUDA's int32 limit. Needed past roughly 10.5s at 1344×768 — beyond that you get CUDA error: an illegal memory access was encountered, usually surfacing at some later unrelated allocation. Not an approximation: these projections are row-wise, so it computes the same function.

H3 Sliding Window

model, window, follow_taps, jitter, isolate_references, start_percent, end_percent → MODEL, report

Restricts each latent frame's attention to a band of nearby frames, plus rotating long-range taps so distant frames still reach each other. Text and references stay fully attended. Measured 1.7× at 5s, 3.2× at 10s. Needs a Triton-capable GPU; falls back to dense attention otherwise.

H3 Reference Isolate

model, start_percent, end_percent → MODEL, report

Stops the reference prefix attending to the denoising target — one square attention becomes two rectangular ones. One-directional: the generation still sees its references. Saves in proportion to how much of the sequence is references, 25% with a full-res video reference, and costs no memory.

Latent

H3 Decode Frames

samples, vae, index, count, stride → IMAGE, total_frames

Decodes selected frames instead of the whole clip. The VAE works in overlapping 17-frame chunks, so one frame costs at most two chunk decodes. index is negative from the end. count=8 stride=1 gives eight consecutive frames; count=6 stride=20 samples six points across a clip.

H3 Latent Slice

samples, start, count, audio → LATENT, latent_frames

Slice a latent on the token axis.

Development

Pure Python, no build step — edit a file and restart ComfyUI.

__init__.py       the NODES list
nodes/_base.py    namespace and menu category
nodes/<group>/    the nodes; `_name.py` holds the logic each is thin over
docs/             reasoning and measurements that would bloat this file

uvx ruff check . && uvx ruff format .

License

MIT
