ComfyUI-Montagen

ComfyUI Video Studio with Node-Controlled Timelines for Multi-Task Production.

Key Features

🎞️ Node-Controlled Timeline Architecture

• Parameterized Timeline Setup
  • Set resolution/FPS via Create Timeline nodes
  • Initiate batch rendering with Execute Timeline nodes
  • Deep integration between node workflows and video timelines
• Bi-Directional Metadata Sync
  • Real-time synchronization between node parameters and timeline properties
  • Reverse-tweak generated content via editor-side adjustments

🖥️ Integrated Production Workspace

• Unified Preview
  • Timeline visualization embedded in ComfyUI interface
  • Asset preview through Editor and Player component
• Structured Project System
  • Standard directory templates (assets//workflows//timelines/)
  • Hybrid protocol support (Local/HTTP/SMB/FTP) for unified resource management

🚀 Batch Production Pipeline

• Multi-Timeline Rendering
  • Each timeline produces one video
  • Centralized output management via builds/ directory
• Prebuilt Scenarios (In Development)
  • Digital human video synthesis
  • Batch processing templates
  • Novel-to-video automation

Usage

Step 1, Open Project

1. Select Montagen icon from ComfyUI Activity Bar, to display Montagen Explorer.
2. Start from default project, or click Browse project to enter custom project folder path.
3. Click Open project to open recent project.

Step 2, Create Timeline

1. Add Create Timeline node and set up timeline paramters.
2. Add Clip Adapter nodes, set up paramters, and connect to the Create Timeline node.
3. Run workflow to create timeline.

Step 3, Timeline Editing

1. Select timeline from project Explorer panel, to display timeline Editor and Player.
2. Select specify clip and open Nodes and Properties Explorer panel, to display the clip's metadata.
3. Edit with timeline or Properties panel, to update the timeline.

Step 4, Timeline Rendering

1. Add Execute Timeline node and set up file name, and connect to the Create Timeline node.
2. Run workflow to rendering timeline.
3. Select builds/ from project Explorer panel, and preview output files.

CHANGELOG [0.2.0] - 2025-04-03

Architected Release: Project-Structured Video Production Framework with Node-Controlled Timelines for ComfyUI.

Added

• [Core] Project System:
  • Standalone Project Directory: Create/import projects with dedicated subdirectories.
  • Consolidated Resource Management: Unified storage for workflows, timelines, and assets.
  • Task-oriented Pipeline: Sequential video editing task processing within project scope.
  • assets/: Local asset storage.
  • assets-ref/: Virtual file system for remote assets (Supports: HTTP/SMB/FTP/Local).
  • builds/: Timeline rendering outputs.
  • workflows/: Montagen-enhanced ComfyUI workflows.
  • timelines/: Video output configurations (1 timeline = 1 video).
  • tmp/: System cache (UI hidden).
  • project.montagen: Project manifest (UI hidden).
• [Core] Explorer System:
  • Project Selection: Open recent/custom projects, browse project directories, and refresh project structure.
  • Unified Activity Bar: Integrated control panels with contextual binding.
  • project Panel: Visualizes directory hierarchy.
  • nodes Panel: Displays workflow/timeline items.
  • properties Panel: Metadata inspector with two-way data binding.
• [UI] Unified Preview:
  • Unified Asset Preview: Asset preview through Editor and Player component.
  • Inline Timeline Preview: Timeline visualization embedded in ComfyUI interface.
• [Node] Montagen Timeline Nodes:
  • Create Timeline: Initialize with name, width, height, fps parameters.
  • Execute Timeline: Render timeline to file with custom output name (e.g. "final.mp4").

Changed

• [Core] Project System:
  • Exclusive Project Focus: Only one project can be actively edited at any time.
  • Multi Workflows: Node-based blueprinting, each workflow defines specific editing processes.
  • Multi Timelines: Each timeline produces one video. Multiple timelines allow sequential generation of multiple videos.
• [UI] project Panel:
  • assets\: Upload assets to the project directory.
  • assets-ref\: Add remote assets as a native file (Supports: local path, HTTP, SMB, FTP).
• [UI] nodes Panel:
  • Workflow Items: Display Montagen nodes of the selected workflow.
  • Timeline Items: Display Montagen clips of the selected timeline.
• [UI] properties Panel:
  • Asset Metadata: Technical specifications and origin data.
  • Clip Properties: Timeline parameters with two-way binding to Editor and Player.
• [Node] Adapter Node Paramters Overview:
  • resources: Optional input. (In Development)
  • timeRange: Optional input. (In Development)
  • metas: Optional input. (In Development)
  • MONTAGENCLIPS: Optional output. (In Development)
  • name: Required, clip id.
  • enableInput: Default fasle. Set true when optional input is used.
  • tag: Optional input. (In Development)
  • file: [file | mediaInput]. Choose file to upload instead of media input.
  • mediaInput: [file | mediaInput]. Use media input instead of choose file to upload.
• [Node] Adapter Node Type:
  • Image Clip Adapter: Default clip duration is 3s.
  • Video Clip Adapter: With preview_fps.
  • Sticker Clip Adapter: With preview_fps like Video Clip Adapter, display in specify timeline track.
  • Audio Clip Adapter: No specify paramters.
  • Text Clip Adapter: With no mediaInput, the clip content can be updated through Properties panel.

Removed

• [UI] Montagen Page:
  • Deprecated Components: Legacy Navigation System, and sandalone Tab for Editor and player.
  • Feature Migration: Full integration into ComfyUI interface. And Explorer System replaces legacy Navigation System.

Installation

Install via ComfyUI-Manager

• Search ComfyUI-Montagen in ComfyUI-Manager and click Install button.

Manual Install

To install ComfyUI-Montagen in addition to an existing installation of ComfyUI, you can follow the following steps:

1. Goto ComfyUI/custom_nodes dir in terminal (cmd)
2. git clone https://github.com/MontagenAI/ComfyUI-Montagen.git
3. Restart ComfyUI.

Acknowledgments

• Base on the project of FFCreator. And inspired by the examples of miravideo.
• Reference portions of media loading/preview code from ComfyUI-VideoHelperSuite into our custom node implementation.
