AnimoFlow

comfyui-animoflow

Text-to-motion animation in ComfyUI: state-of-the-art motion models (MDM, priorMDM, MoMask, Kimodo) each in its own Docker container, plus nodes for resampling, IK cleanup, character rigging, and GLB/FBX export. Type a prompt, get a rigged animation on a real character.

The node pack is open source (AGPL-3.0, commercial dual license available). The broader AnimoFlow platform is source-available and free forever for individuals, non-profits, and academia — see the licensing page.

Install

Two pieces: the nodes (into ComfyUI, like any custom-node pack) and the model backend (Docker containers, one command).

1. Nodes — via ComfyUI-Manager (search "AnimoFlow"), or manually:

cd ComfyUI/custom_nodes
git clone https://github.com/AnimoFlow/comfyui-animoflow.git
# Manager installs requirements.txt for you; manual installs:
#   <ComfyUI's python> -m pip install -r comfyui-animoflow/requirements.txt

2. Model backend — from the cloned directory:

cd comfyui-animoflow
./install.sh doctor     # preflight: Docker, ports, disk, weights, Blender
./install.sh weights    # downloads MDM weights; prints SMPL instructions
./install.sh up         # builds + starts the containers (first run: 15-25 min)

install.sh status shows per-model health including whether weights are actually loaded — run it whenever something seems off, then see TROUBLESHOOTING.md.

3. First workflow — restart ComfyUI, then drag any JSON from workflows/ onto the canvas (start with text_momask) and hit Queue Prompt. The result plays right on the canvas in a 3D viewport.

Works on: macOS (Apple Silicon & Intel), Linux, Windows via WSL2. No GPU required — MDM/priorMDM/MoMask run on CPU; Kimodo is the GPU-only exception (./install.sh up --gpu on an NVIDIA machine). Weight sources and licenses: WEIGHTS.md.

Serving a Blender team? Your local stack can back the AnimoFlow Blender add-on for every seat on your network — run animoflow-api in front of your ComfyUI. See the self-hosting guide.

More documentation

• User guide — all the ways to use AnimoFlow: https://animoflow-alpha.pages.dev/guide/
• All AnimoFlow repositories: https://github.com/AnimoFlow
• In this repo: WEIGHTS.md · TROUBLESHOOTING.md · community/CONTRACT.md (plug in your own model)

What's in here

comfyui-animoflow/
├── __init__.py            # ComfyUI package root — symlink THIS DIR into custom_nodes/
├── animoflow_stages/      # SHARED STAGE LIBRARY — single source for pipeline shape,
│   │                      #   per-model params, resample, and the unified GLB export.
│   │                      #   Consumed by BOTH executors: these nodes AND the HF
│   │                      #   Space's pipeline_hf.py.
│   ├── plan.py               build_plan() + to_comfyui_workflow() (API server compiles this)
│   ├── genparams.py          per-model input mapping incl. the root2d constraint
│   ├── resample.py           NPZ time-resample (stamps the authoritative fps key)
│   ├── glb_export.py         options + Blender-subprocess runner
│   ├── blender_glb_export.py THE one FBX→GLB Blender script (snap, traj-restore,
│   │                         brand tint/matte, phantom strip, shared keyframe RDP)
│   ├── glb_post.py           gltfpack compression + texture downsize
│   ├── brand.py              Y_bot tint + matte-character policy
│   └── fps.py                per-model native FPS table
├── containers/            # One Docker image per model (per-model dep isolation)
│   ├── mdm/                  POST /generate → NPZ pose tensor
│   ├── priormdm/             POST /generate with trajectory / sample_id
│   ├── momask/               MoMask
│   ├── kimodo/               (CUDA-only, behind gpu profile; root2d constraint support)
│   ├── retargeter/           Blender retargeting + SMPL↔SOMA conversion
│   └── comfyui/              (optional) containerized ComfyUI
├── nodes/                 # ComfyUI custom nodes (native — thin HTTP clients to containers)
│   ├── prompt_rewrite_node.py   AnimoFlow_PromptRewrite (wraps animoflow_stages.rewrite)
│   ├── mdm_node.py              AnimoFlow_MDM
│   ├── priormdm_node.py         AnimoFlow_PriorMDM + AnimoFlow_PriorMDMTimeline
│   │                            (Timeline carries the webui's NLE segment
│   │                             editor — see web/animoflow_timeline.js)
│   ├── momask_node.py           AnimoFlow_MoMask
│   ├── kimodo_node.py           AnimoFlow_Kimodo (text / trajectory / waypoints)
│   ├── draw_nodes.py            AnimoFlow_DrawTrajectory + AnimoFlow_DrawWaypoints
│   │                            (interactive draw pads — see web/js/animoflow_draw.js)
│   ├── resample_node.py         AnimoFlow_Resample (wraps animoflow_stages.resample)
│   ├── ik_node.py               AnimoFlow_IK (native — Joint2BVHConvertor)
│   ├── rig_node.py              AnimoFlow_Rig (native retargeter)
│   ├── glb_export_node.py       AnimoFlow_GLBExport (wraps animoflow_stages.glb_export)
│   ├── pose3d_node.py           AnimoFlow_SmplToOpenPose3D (video control demo)
│   ├── camera_node.py           AnimoFlow_Camera (video control demo)
│   ├── openpose_render_node.py  AnimoFlow_OpenPoseRender (video control demo)
│   ├── foot_skating_fix_node.py AnimoFlow_FootSkatingFix
│   ├── outlier_fix_node.py      AnimoFlow_OutlierFix
│   └── preview3d_node.py        AnimoFlow_FBXToPreview3D
├── characters/            # Drop .fbx here → auto-discovered by AnimoFlow_Rig
├── workflows/             # CURATED workflows (GUI format; API format in workflows/api/)
├── docker-compose.yml     # Model containers + shared network
├── docker-compose.dev.yml # Opt-in hot-reload overlay for wrapper source
├── start.sh               # Boots compose + ComfyUI + animoflow-api (maintainer convenience)
└── setup.sh               # First-time Python venv + ComfyUI install

The 5-layer architecture

Web UI (animoflow-webui, served on :8090)
     │
     ▼
API Gateway (animoflow-api, FastAPI, :8090)
     │  compiles animoflow_stages.plan → ComfyUI workflow JSON
     ▼
ComfyUI Orchestrator (~/ComfyUI, :8188)  ← native python, runs the node graph
     │
     ▼
Custom Nodes (nodes/)  ← utility nodes native; model nodes are HTTP clients
     │        └── shared stage library (animoflow_stages/)
     ▼  HTTP /generate
Model Containers (containers/*/, Docker)

The same stage library is imported by the HF Space executor (animoflow-app/pipeline_hf.py), so the hosted pipeline and this node graph cannot drift: pipeline shape, per-model parameter mapping, the resample stage, and the FBX→GLB Blender script are all single-sourced here.

The split is deliberate: orchestrators run native, models run containerized — see “Why containers per model” below.

Developing on this repo

./install.sh above covers users. For working on the nodes/stages themselves, run ComfyUI natively with this repo symlinked into custom_nodes/ (the repo ROOT, not nodes/ — the nodes import the stage library as a sibling package) and keep the containers up via ./install.sh up. start.sh is a convenience that boots compose + a native ComfyUI + animoflow-api together.

Per-model weight sources, sizes, and licenses: WEIGHTS.md.

Why containers per model

Each research repo (MDM, priorMDM, MoMask, Kimodo, …) has its own dependency tree, often with pinned versions that conflict with each other. Running them all in a single Python process is a dependency-hell disaster — the AUTOMATIC1111 ecosystem is the canonical cautionary tale.

Per-model Docker containers solve this cleanly:

• OS-level isolation — each container has its own torch, numpy, CUDA, system libs.
• Same HTTP contract across models — a container's /health + /infer endpoints are runtime-agnostic. The same spec deploys on K8s / Modal / RunPod / NVIDIA NIM in production.
• Clean contributor pattern: adding a new Tier-2 model is "write a Dockerfile" — no changes to the rest of the stack.

ComfyUI + animoflow-api run native because they're orchestrators, not inference — wrapping them in containers would only add inter-process latency without any isolation benefit.

Wrapping upstream models

AnimoFlow does not fork the upstream research repos (MDM, MoMask, priorMDM, Kimodo, AnyTop). They are pinned clones wrapped in our containers/<model>/app.py + containers/<model>/inference.py. Any fixes we need to apply to upstream live in patches/ and are applied via git apply at container build time — upstream repos stay pristine, pinned, and correctly attributed.

The ComfyUI GUI is a supported interface

The node graph at http://localhost:8188 is a first-class AnimoFlow surface with full parity with the hosted webUI: every task (text, trajectory, waypoints, timeline), every model (MDM, priorMDM, MoMask, Kimodo), every character, multilingual prompting (see below), snap-to-ground, trajectory restore, keyframe reduction, and the optional gltfpack/texture post-steps.

Multilingual prompting: the text_kimodo_multilingual curated workflow starts with an AnimoFlow_PromptRewrite node — type a prompt in any language into it and it is rewritten to a HumanML3D-style English caption (Qwen2.5-1.5B + retrieval few-shot, the same rewriter the hosted webUI uses; the shared core is animoflow_stages/rewrite.py). Because the prompt input of the generator node is linked, you type into the rewrite node, not the generator. The node is generic — drop it in front of any generator in your own graphs. Notes:

• Mode dropdown — auto (default: rewrite unless the input already looks like a HumanML3D caption), force, skip (pass through).
• The default demo prompt skips instantly — the cheap heuristic recognizes HumanML3D-style English and never touches the model.
• First real rewrite lazy-downloads ~3.2 GB from HF Hub (Qwen + MiniLM retriever + caption corpus, one-time; override sources via the REWRITER_MODEL_REPO / REWRITER_RETRIEVER_REPO / REWRITER_CORPUS_REPO / REWRITER_DATA_DIR env vars; set REWRITER_DISABLED=1 to make every call a pass-through).
• Failures are loud — if the rewriter can't load, the node errors red; it never silently passes the original prompt through (project no-silent-fallback policy).
• Timeline (timeline_priormdm) segments are not rewritten in the GUI yet — a segments-aware node variant is a known follow-up. (API-driven timeline jobs do get per-segment rewriting, at the API layer.)

Curated workflows live in workflows/ (drag-drop into the ComfyUI canvas; each ends in the built-in Preview 3D & Animation viewport — play/scrub the result right on the canvas) with API-format twins in workflows/api/ (POST them to /prompt, or use them programmatically):

| Workflow | Task | Model | Notes | |---|---|---|---| | text_mdm / text_momask / text_kimodo | text | MDM / MoMask / Kimodo | the standard 5-stage pipeline | | text_kimodo_multilingual | text | Kimodo | AnimoFlow_PromptRewrite at the head — prompt in any language | | trajectory_priormdm | trajectory | priorMDM | interactive draw pad → root inpainting | | trajectory_kimodo | trajectory | Kimodo | interactive draw pad → dense root2d constraint | | waypoints_kimodo | waypoint | Kimodo | interactive pin pad → sparse root2d constraint | | timeline_priormdm | timeline | priorMDM | double-take long motion | | text_mdm_openpose_preview | video control demo | MDM | raw motion → OpenPose control video, previewed as WEBP (CPU-only) | | text_kimodo_video | video control demo | Kimodo + Qwen-Image (pose ControlNet) + Wan 2.2 Fun-Control | official example, fully seeded — pose-conditioned in-flow reference frame + control video drive Wan video generation (needs CUDA + weights); expected outputs checked in at workflows/examples/text_kimodo_video/ |

They are generated, not hand-maintained: python scripts/gen_workflows.py rebuilds all of them from animoflow_stages/plan.py (the two video demos are hand-authored in the same script — they are a demo branch, deliberately not part of the product plan), and tests/test_stage_lib.py fails if the shipped JSONs drift from the generator. Kimodo workflows need the GPU container (docker compose --profile gpu up kimodo -d).

Video control demo: the raw pre-IK joints (straight out of AnimoFlow_Resample, no retargeting) are converted to OpenPose BODY_18 keypoints, filmed by a virtual camera (track follows the character, frame_all fits the whole trajectory; azimuth/elevation/distance/FOV knobs), and rasterized in the exact controlnet_aux/DWPose drawing convention that pose-conditioned video models expect. text_kimodo_video is fully self-contained: Kimodo generates the motion (5.2 s @ 30 fps → resampled to 16 fps and clamped to Wan's 4n+1 = 81 frames), Qwen-Image generates the reference frame in-flow pose-conditioned on the control video's first frame (InstantX union ControlNet in pose mode — both Apache-2.0 — so the still and the motion can't conflict; the image prompt states the character's orientation to the camera to match the camera azimuth), and Wan 2.2 Fun-Control (fp8, two-stage sampling, 81 frames @ 16 fps @ 832×480) animates that character with the AnimoFlow motion. Model files per the ComfyUI Wan 2.2 Fun-Control tutorial and the Qwen-Image tutorial.

Expected results — the workflow ships fully seeded (1309, the winning config of a 30-run sweep), so a run reproduces the checked-in example outputs in workflows/examples/text_kimodo_video/:

ref_frame.png (pose-conditioned still, above) · control.mp4 (OpenPose control video) · final.mp4 (the Wan result). Runtime ≈ 30 min on a 16 GB GPU (fp8 offload). Optional: pip install opencv-python-headless in the ComfyUI venv for pixel-exact controlnet_aux parity (a PIL fallback renders near-identical frames without it).

Nodes quick reference

| Node | Class | Role | |------|-------|------| | Prompt Rewrite | AnimoFlow_PromptRewrite | any language → HumanML3D-style English caption (shared animoflow_stages/rewrite.py; GUI-only — the API rewrites at its own layer) | | MDM Generate | AnimoFlow_MDM | text → NPZ (HTTP to mdm container) | | priorMDM Generate | AnimoFlow_PriorMDM | text + trajectory/sample_id → NPZ | | priorMDM Timeline | AnimoFlow_PriorMDMTimeline | segment list → long-motion NPZ | | MoMask Generate | AnimoFlow_MoMask | text → NPZ | | Kimodo Generate | AnimoFlow_Kimodo | text (+ optional root2d trajectory/waypoints) → NPZ/BVH/SOMA | | Draw Trajectory | AnimoFlow_DrawTrajectory | in-canvas draw pad (webui-style): freehand curve → canonical curve_2d + root2d + traj_restore | | Draw Waypoints | AnimoFlow_DrawWaypoints | in-canvas pin pad: numbered pins → root2d + traj_restore | | Resample | AnimoFlow_Resample | NPZ fps change; stamps the authoritative fps key | | IK | AnimoFlow_IK | NPZ → BVH (native, Joint2BVHConvertor) | | Rig | AnimoFlow_Rig | BVH + character FBX → output FBX (native retargeter) | | GLB Export | AnimoFlow_GLBExport | FBX → GLB via the shared Blender script (snap, tint/matte, traj-restore, RDP; optional gltfpack/texture post-steps) | | FootSkatingFix | AnimoFlow_FootSkatingFix | BVH filter | | OutlierFix | AnimoFlow_OutlierFix | BVH filter | | SOMA→SMPL | AnimoFlow_SomaToSmpl | skeleton-format conversion (Kimodo SOMA → 22-joint) | | Preview | AnimoFlow_FBXToPreview3D, AnimoFlow_PreviewFBX, AnimoFlow_PreviewMotion | visualization in ComfyUI | | SMPL → OpenPose 3D | AnimoFlow_SmplToOpenPose3D | raw pre-IK NPZ → BODY_18 keypoints in 3D (nose/eyes/ears synthesized from head + facing) | | Camera | AnimoFlow_Camera | POSE3D → per-frame pinhole camera (track / frame_all, azimuth/elevation/distance/FOV; owns the video width×height) | | OpenPose Render | AnimoFlow_OpenPoseRender | POSE3D + camera → IMAGE batch in the controlnet_aux/DWPose drawing convention (control video for Wan et al.) |

Caching: ComfyUI caches node outputs. Changing only character reruns only AnimoFlow_Rig + AnimoFlow_GLBExport — model + IK outputs are reused.

Headless test coverage

python -m pytest tests/                       # everything below
python -m pytest tests/test_stage_lib.py      # stage library units + workflow-drift guard
python -m pytest tests/test_glb_export_headless.py  # real Rig→GLB run; asserts the
                                              # Y_bot brand tint, matte flatten, phantom
                                              # strip and snap sidecar in the output GLB

Fallback: running without Docker

If Docker isn't an option (locked-down hosts), each container's app.py can run as a plain uvicorn process in a venv that satisfies its requirements — the nodes only care that something answers on the configured ports. This is a fallback, not a supported path: you lose the per-model dependency isolation that the containers exist to provide.

Adding characters

Drop any Mixamo-rigged .fbx into characters/ → auto-appears in both the web UI character dropdown and the AnimoFlow_Rig node dropdown. Characters include embedded textures (embed_textures=True in Blender export).

Notes

• ComfyUI is not containerized — only research models that need dep isolation go in Docker.
• AnimoFlow_IK uses a sys.modules eviction trick to prevent ComfyUI's utils package from shadowing momask's utils (the kind of import-collision that motivates the per-model container architecture).

Further reading

• WEIGHTS.md — where every model's weights come from, sizes, licenses
• TROUBLESHOOTING.md — symptoms → causes → fixes
• community/CONTRACT.md — the HTTP contract for plugging in your own model
• User guide — the non-technical overview

Licensing

This node pack is open source under AGPL-3.0, copyright (c) 2026 Guy Tevet ("AnimoFlow"). In short: use it freely, including commercially — but if you modify it and distribute it, or run a modified version as a network service, you must make your modified source available under the same license.

Commercial dual license. Organizations that want to use these nodes without AGPL-3.0 obligations (for example, inside a proprietary hosted service) can obtain a commercial license instead — contact [email protected]. Commercial licensing is not yet open; ask to join the waitlist and you'll hear first.

Contributions. External contributions require a one-time Contributor License Agreement (CLA) so the project can keep offering the dual license — a bot will ask on your first pull request. Details, CLA text, and the full AnimoFlow per-repo license map: AnimoFlow/legal.

Model weights and third-party components keep their own licenses — see WEIGHTS.md. The headless retargeting script (nodes/retargeter/retarget_keemap.py and its container copy) derives from the KeeMap addon by Nick Keeline and remains under GPL-3.0 (LICENSES/GPL-3.0.txt), compatible with this repository's AGPL-3.0.
