ComfyUI OpenRouter Node

A custom node for ComfyUI that allows you to interact with OpenRouter's chat/completion API, providing access to a wide range of LLM models including GPT-4, Claude, Llama, Mistral, and more.

Multiple image inputs are supported. Make sure the model you are using supports multiple images to be sent at once. Thanks @wTechArtist for the idea!

Features

• Access to all models available on OpenRouter
• Support for multiple image inputs (up to 10 images)
• Dynamic image input visibility - additional inputs appear as you connect images
• PDF support with multiple OCR engine options
• Web search capability with :online modifier
• Cheapest provider routing with :floor modifier
• Fastest provider routing with :nitro modifier
• Detailed statistics on token usage and generation speed
• Real-time OpenRouter account balance display

Installation

1. Clone this repository into your ComfyUI custom_nodes folder:

cd ComfyUI/custom_nodes
git clone https://github.com/gabe-init/ComfyUI-Openrouter_node

2. Install the required dependencies:

pip install -r requirements.txt

3. Restart ComfyUI

Usage

The OpenRouter node provides a simple interface to interact with various LLMs through the OpenRouter API.

Inputs

Required Inputs:

• api_key: Your OpenRouter API key. You can get one from OpenRouter.
• system_prompt: The system prompt that sets the behavior of the LLM.
• user_message_box: The user message to send to the LLM.
• model: The model to use for generation. The node automatically fetches the list of available models from OpenRouter.
• web_search: Enable web search capability by appending :online to the model ID. This costs $4 per 1000 queries and automatically uses your openrouter balance.
• cheapest: Route to the cheapest provider by appending :floor to the model ID (enabled by default).
• fastest: Route to the fastest provider by appending :nitro to the model ID (disabled by default).
• temperature: Controls the randomness of the model's output (0.0 to 2.0).

Optional Inputs:

• image_1 through image_10: Multiple image inputs for multimodal models. The first image input (image_1) is always visible. Additional image inputs automatically appear as you connect images (up to 10 total).
• pdf_data: PDF document input for models that support document understanding.
• pdf_engine: Choose between "auto", "mistral-ocr", or "pdf-text" for PDF processing.
• user_message_input: Alternative input for the user message, useful for connecting to other nodes.

Outputs:

• Output: The text response from the LLM.
• Stats: A string detailing tokens per second, input tokens, output tokens, temperature, and the model used.
• Credits: A string showing your remaining OpenRouter account balance (e.g., "Remaining: $9.792").

Note: To display the output text in ComfyUI, you can use the ShowText nodes from ComfyUI-Custom-Scripts, but any text display node will work.

Examples

Basic Text Generation

1. Add the OpenRouter node to your workflow
2. Enter your API key
3. Set a system prompt (e.g., "You are a helpful assistant.")
4. Enter a user message (e.g., "Explain quantum computing in simple terms.")
5. Select a model (e.g., "openai/gpt-4")
6. Run the workflow

Image Understanding

1. Add the OpenRouter node to your workflow
2. Connect an image output from another node to the "image_1" input
3. Enter your API key
4. Set a system prompt (e.g., "You are a helpful assistant.")
5. Enter a user message (e.g., "Describe this image in detail.")
6. Select a multimodal model (e.g., "openai/gpt-4-vision" or "anthropic/claude-3-opus-20240229")
7. Run the workflow

Multiple Image Analysis

1. Connect your first image to "image_1"
2. As soon as you connect it, "image_2" will automatically appear
3. Connect additional images as needed (up to 6 total)
4. Unused image inputs will automatically hide when disconnected
5. Enter a prompt that references multiple images (e.g., "Compare these images and describe the differences.")
6. Select a multimodal model that supports multiple images
7. Run the workflow

Note: The user is responsible for checking if their selected model supports multiple images. Most modern multimodal models (4o, Gemini Flash, etc.) support multiple images in a single request.

Routing Options

• For cost-effective responses, enable the "cheapest" option (on by default)
• For faster responses, disable "cheapest" and enable "fastest"
• For web search capability, enable "web_search"

Troubleshooting

• Model list not loading: Check your internet connection and OpenRouter API key.
• Error in response: Check the error message in the output. It might be due to an invalid API key, model unavailability, or other API issues.
• Slow responses: Try using the :nitro modifier by enabling the "fastest" option.
• Token counting issues: The node uses tiktoken for accurate token counting, but falls back to an estimation method if there's an issue.
