๐๏ธ Interior Design for ComfyUI v2.0
</div>This project adapts the original pipeline from
StableDesign: 2nd place solution for the Generative Interior Design 2024 competition
to work natively and fully inside ComfyUI, leveraging modern custom nodes and a modular architecture.
Learn more about the original method in this Medium article.
โ Key Features
- Fully restructured for ComfyUI compatibility
- Includes 3 custom nodes developed specifically for this repository:
"Interior Design Segmentator"
"Image Normalize"
"Control Items"
- Uses additional advanced custom nodes:
- Reimplements only the necessary components from the original pipeline, such as:
- Semantic segmenter using
openmmlab/upernet-convnext-small
- Semantic segmenter using
- Supports standard ComfyUI workflows with ControlNet and IP Adapter integration
- Compatible with other workflows and custom models
- Inference is significantly faster than the original pipeline (test the workflow and compare).
๐งฑ Pipeline Overview
- The idea was to use as many nodes from the ComfyUI core as possible. However, for certain tasks, I had to rely on custom nodes or adapt my own nodes to stay as faithful as possible to the original pipeline, or alternatively, use dependencies from other custom node repositories.
- Uses the same base models as the original StableDesign pipeline
- Includes custom ControlNet models:
controlnet_depth
own_controlnet
(segmentation)
- These ControlNets, along with the depth map and segmentation map, are passed into the UNet of the diffusion model
- Final step includes refinement with latent noise injection and up/down-scaling(because of the size limitation of the original pipeline)
๐ Example Workflow
An example workflow is included in this repository:
stable-design-for-comfyui.json
You can load it directly into ComfyUI to test or extend the pipeline.
๐ฆ Installation & Dependencies
This node is available on ComfyUI Manager
You must also install the following custom nodes manually if not yet available:
- Depth Anything V2
- ComfyUI_IPAdapter_plus (note: unmaintained)
- ComfyMath
๐ง Upcoming Features
- Expansion of Control Items: Add support for more semantic regions and control inputs to increase flexibility and detail in generation.
- Evaluation of CLIP Conditioning: Reassess the combination of positive and negative CLIP embeddings in ControlNet to verify if results match the original pipeline's behavior.
- Custom IP Adapter Node: Implement a native IP Adapter node to replace the current dependency on
ComfyUI_IPAdapter_plus
, which is currently unmaintained.
๐งช License & Acknowledgements
Original pipeline by MykolaL (StableDesign on Hugging Face)
This adaptation reuses only essential logic, converted to full ComfyUI-compatible workflow format.
feel free to open issues and PRs
